ABB Residual Current Circuit Breaker with Overload Protection 10A Current Rating 2-Pole 30mA Trip 2CSR255480R1104



Category Residual Current Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	India
Range	System Pro M Compact
Brand	ABB
Height	85mm
Model	2CSR255480R1104
Depth	69mm
Width	35mm
Mount Type	DIN Rail
Current Rating	10A
Series	DS201
Terminal type	Screw
Breaking Capacity	6kA
Number of Poles	2
Standards/Approvals	IEC, RoHS
Rated AC Voltage	230V ac
Tripping Characteristics	Type C
Tripping Mechanism	Thermal Magnetic
Trip Sensitivity	30mA
Earth Leakage Protection Type	Type A

Key Features

Designed for overload and short-circuit protection of single-phase circuits.
Thermal magnetic tripping mechanism with Type C characteristics.
Equipped with Type A earth leakage protection for enhanced safety.
Mounts easily on DIN rail with screw terminal type connections.
Compact DS201 series device with a width of 35mm, height 85mm, and depth 69mm.
Rated for 230V AC voltage with 6kA breaking capacity.
Conforms to IEC and RoHS standards ensuring compliance and reliability.

Product Description

ABB 2CSR255480R1104 Residual Current Circuit Breaker with Overload Protection is designed to safeguard end-user single-phase electrical circuits against overloads, short circuits, and earth leakage currents. This product features a 10A current rating and a 2-pole design with 30mA trip sensitivity, making it suitable for residential and commercial electrical distribution panels.

Its thermal magnetic tripping mechanism with Type C characteristics ensures reliable disconnection under short-circuit and overload conditions. The earth leakage protection corresponds to Type A, protecting against sinusoidal alternating earth fault currents as well as direct and indirect contact faults.

The device is compact, measuring 35mm wide, 85mm tall, and 69mm deep, and mounts conveniently on standard DIN rails with secure screw terminals for easy installation and maintenance. Rated for 230V AC with a breaking capacity of 6kA, it is compliant with IEC and RoHS standards guaranteeing safety and environmental conformity.

This device is widely applicable in industrial, commercial, and residential electrical infrastructures, offering reliable protection for household appliances, lighting, and small machinery against electrical faults that could cause damage or fire risk.

10A current rating for moderate electrical loads. Thermal magnetic Type C trip characteristics for fast response. Type A earth leakage protection to detect alternating and pulsating direct currents. DIN rail mounting ensures quick and standardized installation.

Compact dimensions to save panel space. Rated voltage 230V AC suitable for standard power systems. Breaking capacity of 6kA to handle typical fault currents. Meets international IEC and environmental RoHS compliance standards.

Explore the ABB range of circuit breakers and electrical components on EnvMart for dependable circuit protection solutions.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This model has a current rating of 10A, making it suitable for moderate electrical loads.

It features a trip sensitivity of 30mA, providing effective earth leakage protection.

It utilizes a thermal magnetic tripping mechanism with Type C characteristics for reliable disconnection during overload and short-circuit conditions.

The breaking capacity of this device is rated at 6kA, allowing it to handle typical fault currents effectively.

This model measures 35mm in width, 85mm in height, and 69mm in depth, making it compact for installation.

It mounts easily on standard DIN rails and features screw terminal type connections for secure installation.

It offers Type A earth leakage protection, which detects both sinusoidal alternating and pulsating direct currents.

This unit conforms to IEC and RoHS standards, ensuring compliance and reliability in electrical installations.

It is rated for 230V AC, suitable for standard power systems in residential and commercial applications.

This model is part of the DS201 series, designed for effective overload and short-circuit protection.

It is widely applicable in industrial, commercial, and residential electrical infrastructures, protecting household appliances and lighting.

This device is designed with 2 poles, suitable for single-phase circuits.
