ABB Residual Current Circuit Breaker with Overload Protection, 16A Current Rating, 1-Pole 2CSR275180R0164 DS201 M C16 A10



Category Residual Current Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	India
Range	System Pro M Compact
Brand	ABB
Height	85mm
Model	2CSR275180R0164 DS201 M C16 A10
Depth	69mm
Width	35mm
Mount Type	DIN Rail
Current Rating	16A
Series	DS201
Terminal type	Screw
Breaking Capacity	10kA
Number of Poles	1
Standards/Approvals	RoHS, IEC
Rated AC Voltage	230V ac
Tripping Characteristics	Type C
Tripping Mechanism	Thermal Magnetic
Trip Sensitivity	10mA
Earth Leakage Protection Type	Type A

Key Features

Incorporates thermal magnetic tripping mechanism to protect against overload and short circuits.
Offers 10 mA trip sensitivity for earth leakage protection ensuring enhanced safety.
Compact two-module width suitable for DIN rail mounting installations.
Designed for 230V AC rated voltage with screw-type terminals for secure connections.
Meets IEC standards and RoHS compliance for quality and environmental safety.
Breaking capacity of 10kA ensures high fault current interruption capability.
Type C tripping characteristics suitable for general use and inductive loads.
IP20 protection for terminals and IP40 for housing increases durability in electrical panels.

Product Description

ABB 2CSR275180R0164 DS201 M C16 A10 Residual Current Circuit Breaker with Overload Protection is engineered for effective protection of end-user single-phase electrical circuits against overload currents, short circuits, and earth faults. Featuring a reliable thermal magnetic tripping mechanism, this device offers precise response to overload and fault conditions, minimizing electrical hazards.

The breaker has a current rating of 16A and a trip sensitivity of 10 mA providing excellent earth leakage protection compliant with Type A leakage current standards. It is designed for installation on a DIN rail with a compact two-module width for optimal space utilization in distribution panels.

Operating at a rated AC voltage of 230V, the device uses screw terminals for secure and reliable wiring. The breaker meets IEC and RoHS standards ensuring safety, reliability, and environmentally conscious manufacturing.

The DS201 series is part of the System Pro M Compact range, popular for its high breaking capacity of 10kA, suitable for typical commercial and industrial electrical distribution systems.

Its construction provides IP20 protection for the terminals and IP40 for the housing, ensuring resistance to ingress of foreign objects and touch protection. Measuring 85mm in height, 69mm in depth, and 35mm in width, it allows for efficient use of space inside electrical enclosures and panels.

Incorporates thermal magnetic tripping for overload and short circuit protection. High sensitivity earth leakage detection at 10 mA ensures user safety. Compact dimensions and DIN rail mounting for flexible installation.

Meets IEC standards and RoHS compliance for quality assurance. Breaking capacity rated at 10kA supports high fault current interrupting. Type C characteristic for versatile tripping behavior suitable for various applications.

Suitable for industrial, commercial, residential, and HVAC electrical panel installations. System Pro M Compact series supports modular electrical systems. Screw terminal connections provide easy and reliable wiring. Provides protection against direct and indirect contacts as well as sinusoidal earth fault currents.
