Celduc SOB8 Series Solid State Relay DIN Rail Mount 600 V AC Load 30 V AC/DC Control SOB8

Celduc SOB8 Series Solid State Relay with model code SOB8 is a DIN rail mount solid state relay designed for industrial electrical applications requiring efficient load switching. It supports a maximum load voltage of 600 V AC and control voltage range of 17 V AC/DC to 30 V AC/DC, suitable for dual input controlling. This relay features screw terminal type connections and a compact form factor measuring 44.8 mm in length, 44.8 mm in width, and 30 mm in height, allowing easy integration into control panels.

The relay utilizes triac output with single pole single throw contact configuration and an on-state resistance of 16mΩ ensuring low conduction losses. It incorporates zero cross switching technology, which reduces electrical noise and switching stress, thereby improving reliability and longevity. Operating temperature ranges from -55°C up to 100°C, making it suitable for demanding industrial environments.

It is a dual solid state relay capable of handling most load types with instantaneous switching and dual input LED display for operational status indication. It is designed with IP20 rating and complies with international standards including RoHS, VDE, CE, CSA, cURus, EAC, and UKCA ensuring safety and environmental compliance. The product is manufactured in France to high-quality standards.

This solid state relay is ideal for use in automation, electrical control, industrial machinery, HVAC systems, and manufacturing environments requiring reliable and noise-free switching. Its compact DIN rail mount design facilitates easy installation in existing electrical control enclosures.

Equipped with screw terminals for secure electrical connections. Features zero cross switching for reduced electrical noise and stress. Designed to operate safely from -55°C to 100°C ambient temperature range. Compact dimensions of 44.8mm length, 44.8mm width and 30mm height for efficient DIN rail mounting.

Output type is triac with SPST contact configuration for single pole single throw switching. Has an on state resistance of 16mΩ and off state leakage current of 1mA ensuring minimal power loss. Complies with RoHS, VDE, CE, CSA, cURus, EAC and UKCA standards for quality and safety.

Dual solid state relay technology supports most load types and includes dual input LED display. Explore the full range of Solid State Relays and electrical automation products on EnvMart.
