Microchip 8-bit PIC Microcontroller, 7kB FLASH, 32 MHz, 20-Pin PDIP PIC16F18344-I/P

Microchip PIC16F18344-I/P is a high-performance 8-bit PIC microcontroller designed for versatile general-purpose and low power applications. Featuring 7kB of Flash program memory and operating up to 32 MHz clock frequency, this device combines advanced peripheral modules with an enhanced mid-range core to optimize your embedded system design.

The microcontroller supports various communication interfaces such as EUSART, SPI, and I2C, which expands its utility in industrial, automotive, consumer electronics, and control systems. The Peripheral Pin Select (PPS) feature provides exceptional flexibility by allowing re-mapping of digital peripherals including comparators, PWM, and communication pins, facilitating customized board layouts and simplified routing.

Equipped with 18 programmable I/Os, 17-channel 10-bit ADCs, one 5-bit DAC, two analog comparators, and seven timers, this device offers broad analog and timing functionalities. It further supports ultra-low power modes including IDLE and DOZE, combined with an extended watchdog timer, making it ideal for battery-powered and energy-conscious applications.

Constructed with a 20-pin PDIP package, the microcontroller is suitable for through-hole mounting, simplifying prototyping and manual assembly. Its temperature operating range from -40°C to 85°C ensures reliability in harsh environmental conditions. The device uses FLASH memory for program storage with self-read/write capabilities and integrates EEPROM, adding data retention flexibility.

Typical applications include embedded control, industrial automation, instrumentation, signal processing, and other low power microcontroller use cases. Extremely low power consumption for efficient operation. Integrates 7kB Flash program memory with self-read/write capability.

Supports multiple communication interfaces including EUSART, SPI, and I2C. Includes Peripheral Pin Select for flexible digital peripheral pin mapping. Equipped with 18 programmable I/Os and 17 ADC channels for versatile use.

Operates within a wide temperature range from -40°C to 85°C. Incorporates multiple timers, analog comparators, and DAC functionality. Designed with RISC architecture ensuring fast instruction execution. Compatible with through-hole mounting in a standard 20-pin PDIP package.

Offers extended watchdog timer and multiple low-power modes for reliability. Explore the Microchip Microcontrollers category on EnvMart for similar high-quality semiconductor products suited to your electronic component requirements.
