Fluke Intrinsically Safe Dual Range Precision Pressure Calibrator 721EX -0.83 bar to 6.9 bar, Differential Fluke-721EX-1615

Free Delivery in India | Lowest Global Shipping Charges

Fluke Intrinsically Safe Dual Range Precision Pressure Calibrator 721EX -0.83 bar to 6.9 bar, Differential Fluke-721EX-1615

Name: Fluke Intrinsically Safe Dual Range Precision Pressure Calibrator 721EX -0.83 bar to 6.9 bar, Differential Fluke-721EX-1615
Brand: FLUKE
SKU: 272253
Price: 20.22 USD
Availability: InStock



Category Pressure Calibrators Brand FLUKE Condition New

Specifications

Country of Origin	China
Resolution	0.0001 bar
Accuracy	±0.025 %
Brand	Fluke
Height	200mm
Length	110mm
Model	Fluke-721EX-1615
Gross Weight	539g
Width	58mm
Maximum Operating Temperature	45°C
Minimum Operating Temperature	-10°C
Hazardous Area Certification	IECEx/ATEX
Maximum Pressure Measurement	6.9bar
Minimum Pressure Measurement	-0.83bar
Pressure Port Type	Differential

Key Features

Offers dual sensor capability for static and differential pressure measurements.
Achieves a high accuracy of ±0.025% full scale for reliable results.
Equipped with a battery power source for portability and flexibility.
Features a large back-lit graphic display showing two pressure readings plus temperature simultaneously.
Intrinsically safe design certified for hazardous environments with IECEx and ATEX approvals.
Supports 4-20 mA current loop measurement with internal 24 V loop power supply.
Compact size with dimensions of 200 x 110 x 58 mm and lightweight design at 539 g.
Operates effectively within -10°C to 45°C temperature range.

Product Description

The Fluke FLUKE-721EX-1615 is an intrinsically safe dual range precision pressure calibrator designed for use in classified environments, including gas custody transfer applications in potentially explosive atmospheres. It features two isolated stainless steel pressure sensors providing highly accurate measurements from -0.83 bar minimum to a maximum of 6.9 bar differential pressure. The device operates on battery power and offers a large back-lit graphic display capable of showing static pressure, differential pressure, and temperature simultaneously, enhancing usability in industrial, laboratory, and HVAC settings.

This pressure calibrator supports 4 to 20 mA current loop measurements with an internal 24 V loop power supply capable of powering transmitters under test. Its compact form factor measuring 200 x 110 x 58 mm and lightweight of 539 g makes it easy to carry on-site or in the field. The instrument is certified as intrinsically safe under IECEx and ATEX standards (Ex ia IIB T3 Gb), ensuring safety compliance in hazardous area operations.

The instrument supports temperature measurement via a Pt100 RTD input when used with an optional Fluke 720RTD probe. It features configuration flexibility by selecting from multiple low- and high-pressure sensor ranges, accommodating a wide variety of pressure calibration tasks. Up to five user setups can be stored for quick recall and frequent use.

Dual sensor technology for static and differential pressure. High precision with ±0.025% full scale accuracy. Battery powered with back-lit graphic display. Intrinsically safe certification IECEx/ATEX for hazardous environments.

4-20 mA current loop measurement with 24V loop power supply. Compact and lightweight for portability. Operates in a wide temperature range from -10°C to 45°C. Optional temperature measurement with Pt100 RTD input. Store five instrument setups for ease of use.

The Fluke 721EX pressure calibrator is ideal for industrial, laboratory, HVAC, manufacturing, and water treatment applications requiring precise and safe pressure measurement. Explore more Pressure Calibrators and Fluke products on EnvMart to find the ideal calibration solutions tailored to your needs.
