Semikron Danfoss High Voltage Stud Mount Rectifier Diode 1200 V 25 A 2-Pin DO-203AA SKR 26/12

Semikron Danfoss SKR 26/12 is a robust high voltage stud mounting rectifier diode designed for industrial and power electronics applications requiring reliable high current rectification. This diode is housed in a DO-203AA standard package featuring a stud cathode configuration, which facilitates excellent thermal transfer between the device and heatsink, thereby ensuring stable operation under continuous heavy load conditions.

Operating at a maximum continuous forward current of 25 A and a peak reverse repetitive voltage of 1200 V, the SKR 26/12 diode supports high power rectification in applications such as power supplies, motor drives, and industrial converters. Its compact physical dimensions - 63 mm length, 32 mm width, and 22 mm height - with screw mount type allow for secure and efficient thermal management installations.

The diode operates efficiently with a maximum forward voltage of 1.75 V, reducing power dissipation, and can withstand transient peak non-repetitive forward surge currents up to 370 A, enhancing durability against surges and transient voltages. Its operating temperature range from -40°C to 125°C enables use in harsh and variable industrial environments.

This product is supplied with mounting hardware for convenient assembly and is manufactured in Brazil with assured new product condition. The SKR 26 series from Semikron Danfoss represents high reliability hermetically sealed cases ideal for demanding industrial power rectification needs, with the cathode connected to the stud body ensuring superior electrical and thermal coupling.

Stud cathode diode configuration ensures excellent thermal coupling for reliability. Maximum continuous forward current is 25 A for high power handling. Peak reverse repetitive voltage rating of 1200 V supports demanding voltage conditions.

Compact dimensions of 63 mm length, 32 mm width, and 22 mm height with screw mount type. Wide operating temperature range from -40°C up to 125°C for harsh environments. Low maximum forward voltage of 1.75 V minimizes power loss during operation.

Peak non-repetitive forward surge current capacity of 370 A provides transient robustness. Includes mounting hardware for easy installation on heatsinks. Manufactured in Brazil with new product condition assurance.

This diode is well-suited for industrial, manufacturing, power electronics, and electrical equipment applications requiring high voltage and current rectification. Explore the full range of Semikron Danfoss industrial semiconductor components and rectifier Diodes at EnvMart for reliable and efficient power solutions.
