Vishay High Performance Schottky Diode 150 V 400 A 3-Pin TO-240AA VS-VSKCS409/150

Vishay VS-VSKCS409/150 is a high-performance Schottky diode designed for power rectification in demanding industrial and electronic applications. With a maximum continuous forward current rating of 400 A and a peak reverse repetitive voltage of 150 V, this diode provides robust and efficient conduction with minimal power loss.

Housed in a durable 3-pin TO-240AA surface-mount package, the diode offers excellent thermal management and mechanical stability. It is ideal for applications requiring fast switching speed and low forward voltage drop, which reduces the heat generation during operation and improves energy efficiency.

The device supports a wide operating temperature range from -55°C to 175°C, enabling usage in harsh and variable environments typically found in industrial power systems, automotive electronics, and renewable energy systems. Its common cathode configuration makes it suitable for circuit designs that require multiple diode arrangements.

Additional device features include a maximum forward voltage of 1.33 V, a peak non-repetitive forward surge current of 20 kA, and a peak reverse current of 85 mA. These ratings ensure reliable operation under surge and transient conditions typical in power electronics.

Physical dimensions measure 29 mm in height, 92 mm in length, and 22.6 mm in width, facilitating integration into PCB assemblies. The diode is manufactured without specific automotive standard certifications but is designed to meet high-quality performance standards.

Vishay Schottky diodes such as the VS-VSKCS409/150 are commonly used across industrial, manufacturing, power conversion, and electronic equipment applications that demand high efficiency and durability.

This diode features a 3-pin TO-240AA package designed for surface mounting. Peak reverse repetitive voltage is rated at 150 volts for reliable operation. The maximum forward voltage drop of 1.33 V ensures low power dissipation during conduction.

It operates efficiently within a temperature range from -55°C to 175°C. The diode is configured with a common cathode and is suitable for fast switching applications. Maximum peak non-repetitive forward surge current of 20 kA allows tolerance for high transient currents.

The device offers low forward voltage drop and low thermal resistance for enhanced performance. Physical dimensions include a height of 29 mm, length of 92 mm, and width of 22.6 mm. The diode is compliant with no specific automotive standards and does not carry certifications.
