ABB Tmax XT Molded Case Circuit Breaker 3-Pole 50A, Breaking Capacity 25 kA, Fixed Mount 1SDA066804R1 XT1B 160 TMD 50A FF

ABB 1SDA066804R1 XT1B 160 TMD 50A FF Molded Case Circuit Breaker is a high-performance protective device designed for industrial and commercial electrical systems, providing reliable three-pole circuit protection with a rated current capacity of 50 amps and a strong breaking capacity of 25 kA.

This unit operates at a rated AC voltage of 690 V and DC voltage of 500 V, suitable for varied applications. Its fixed mounting type simplifies installation, while the bolt terminal contact design delivers secure electrical connections, enhancing safety and durability.

The breaker features a thermal magnetic tripping mechanism that provides precise protection against overload and short-circuit conditions. The lever-type reset actuator eases manual resets, improving accessibility during maintenance or troubleshooting procedures.

Dimensionally, the circuit breaker has a height of 130 mm, a width of 76.2 mm, and a depth of 70 mm, offering a compact profile for efficient spatial integration in control panels and switchboards.

Constructed to comply with RoHS, IEC, and CE standards, the MCCB ensures adherence to international safety and environmental requirements. With Type B tripping characteristics, it is particularly suited for resistive loads and ensures reliable circuit functionality in various industrial, automation, and motor control applications.

Manufactured in Italy, this ABB Tmax XT series breaker is engineered to deliver robust performance, making it ideal for overload protection in industrial machinery and electrical distribution systems in commercial buildings.

Designed for fixed mounting with a compact form factor for versatile installation. Rated AC voltage is 690 V and rated DC voltage is 500 V to handle diverse electrical systems. Thermal magnetic tripping mechanism ensures precise protection against overloads and short circuits.

Lever-type reset actuator allows quick manual resets for convenient maintenance. Complies with RoHS, IEC, and CE standards for safety and quality assurance. Bolt terminal contact design ensures secure and stable electrical connections.

Type B characteristics suitable for resistive load protection with reliable circuit operation. Compact dimensions of 130 mm height, 76.2 mm width, and 70 mm depth maximize space efficiency. Suitable for industrial machinery protection, commercial electrical distribution, automation, and motor control applications.

Made in Italy with robust construction for long service life. Explore more MCCB models and ABB electrical protection devices at EnvMart for enhanced circuit management and safety in industrial and commercial environments.
