ABB Residual Current Circuit Breaker with Overload Protection 50A 2-Pole 30 mA Trip Sensitivity Type C 230V 2CSR272101R1504

Free Delivery in India | Lowest Global Shipping Charges

ABB Residual Current Circuit Breaker with Overload Protection 50A 2-Pole 30 mA Trip Sensitivity Type C 230V 2CSR272101R1504



Category Residual Current Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Brand	ABB
Height	93mm
Model	2CSR272101R1504
Depth	69mm
Width	70mm
Standards	IEC/EN 60947-2
Current Rating	50A
Series	DS200
Ambient air temperature	Operation -25 ... +55 °C
Terminal type	Screw
Breaking Capacity	6kA
Number of Poles	2
Standards/Approvals	REACH, RoHS, IEC/EN 60947-2
Rated AC Voltage	230V
Tripping Characteristics	Type C
Reset Actuator Type	Lever
Trip Sensitivity	30mA
Earth Leakage Protection Type	Type A
Operating Characteristic	Instantaneous

Key Features

Equipped with instantaneous tripping characteristic Type C for swift fault response.
Complies with IEC/EN 60947-2 and IEC/EN 61009-1 standards ensuring safety and quality.
Features screw terminal type and lever reset actuator for secure and convenient operation.
Designed to protect against overload, short circuit, and earth leakage in residential applications.
Compact dimensions of 93mm height, 70mm width, and 69mm depth for easy integration.
Breaking capacity of 6kA supports robust electrical fault handling.
Performs reliably in ambient temperatures from -25°C to +55°C.
Manufactured in Italy ensuring high-quality build and compliance with RoHS and REACH directives.

Product Description

ABB 2CSR272101R1504 Residual Current Circuit Breaker with Overload Protection is engineered to deliver comprehensive electrical safety by combining overload and short circuit current protection with earth leakage detection. It is part of the DS200 series designed for residential and similar indoor electrical environments.

This 2-pole RCBO supports a rated current of 50A and a trip sensitivity of 30 mA Type A residual current, providing effective protection against direct and indirect contact. The instantaneous Type C tripping characteristic enables immediate disconnection during fault conditions ensuring enhanced safety.

The device operates at a rated AC voltage of 230V and features screw terminals for secure electrical connections. Its compact size (93mm height, 70mm width, and 69mm depth) allows easy installation within standard electrical panels.

Its breaking capacity of 6kA enables it to handle high fault currents. The reset functionality is executed via a lever actuator, providing convenient manual control after a trip event. Compliance with IEC/EN 60947-2 and IEC/EN 61009-1 standards together with certifications like RoHS and REACH ensures that the device meets stringent quality and safety norms.

Applications include residential circuit protection from overload, short circuit, and earth leakage faults, enhancing safety and device integrity. The operating temperature range of -25 to +55 °C makes it suitable for various indoor ambient conditions.

Equipped with instantaneous tripping characteristic Type C for swift fault response. Complies with IEC/EN 60947-2 and IEC/EN 61009-1 standards ensuring safety and quality. Features screw terminal type and lever reset actuator for secure and convenient operation.

Designed to protect against overload, short circuit, and earth leakage in residential applications. Compact dimensions of 93mm height, 70mm width, and 69mm depth for easy integration. Breaking capacity of 6kA supports robust electrical fault handling.

Performs reliably in ambient temperatures from -25°C to +55°C. Manufactured in Italy ensuring high-quality build and compliance with RoHS and REACH directives. Explore more from ABB and other electrical protection devices at EnvMart for dependable industrial and residential electrical safety solutions.
