ABB Residual Current Circuit Breaker with Overload Protection 6A Current Rating 2-Pole 30 mA Trip 2CSR272001R1065

ABB 2CSR272001R1065 Residual Current Circuit Breaker with Overload Protection provides comprehensive safety against overload, short circuits, and earth faults for residential and commercial electrical systems operating at 230V AC.

This 2-pole device rated at 6A current effectively protects circuits with a trip sensitivity of 30 mA, ensuring rapid detection and interruption of earth leakage currents. The type B tripping characteristic allows instantaneous reaction to faults, enhancing safety and equipment protection.

Its lever reset actuator enables convenient manual resetting post-trip, while its busbar terminal ensures reliable electrical connections. The breaker has a breaking capacity of 10kA, making it suitable for handling high fault currents without damage.

With compact dimensions of 93mm height, 69mm depth, and 70mm width, the unit fits well into standard electrical panels. This model complies with IEC/EN 61009-1 and IEC/EN 60947-2 standards, guaranteeing international safety and quality benchmarks.

The device features a 6A current rating and 2 poles for robust circuit protection. It offers a trip sensitivity of 30 mA to detect ground faults effectively. Designed with type B tripping characteristics for instantaneous response.

Rated voltage is 230V AC with a breaking capacity of 10kA to handle short circuits. Equipped with a lever reset actuator for user-friendly operation. Compact dimensions: 93mm height, 69mm depth, and 70mm width for flexible installation.

Utilizes busbar terminal type for secure electrical connections. Conforms to IEC/EN 61009-1 and IEC/EN 60947-2 standards for safety and performance. Earth leakage protection is AC type, preventing electrical faults and hazards.

This Residual Current Circuit Breaker is ideal for ensuring electrical safety and compliance in residential and light commercial applications, providing protection against overloads and earth leakage faults.
