Temperature Scanner 4 Channel-Falcon 1600
Specifications
| Resolution | 12 Bit. RTD PT100- 0.1C T/C JKRSBE- 1C|T type 0.1C| Volt 0.001| mA- 0.01 |
|---|---|
| Accuracy | 0.5% of FSR 1 LSD 1C for CJC |
| Display | 7 Segment RED LED 2 - Digit Channel no. 5 - Digit Process Value with sign. |
| Connections | Screw type connectors on back panel. Male / Female connection for supply & RS485. |
| Input | RTD Pt100 (3wire) 0 - 20 mADC 4-20mA Thermocouples JKRSTBE 0-1VDC and 0-4VDC for each channel. (Combination factory set) |
| Keyboard | 4 Keys tactile keyboard. |
| Supply | 230 VAC / 110 VAC 10 % 50 Hz |
| Cabinet | Horizontal Unit Vertical Unit Bezel 96 x 192mm (H x W) Bezel 192 x 96mm (H x W) Depth 195 mm Depth 195 mm Cutout 92 x 186 mm (H x W) Cutout 186 x 92 mm (H x W) |
| Channels | Max 16 Channels in step of 4 Channels. |
| LED indications | LED indications for Control output status and Serial communication. |
| Scan Rate | 125 msec per channel (16 channels in 2 seconds) |
| Serial Port | Optically isolated RS485 - 2 wire port with MODBUS RTU protocol. Ethernet port optional. |
| Scaling | Scaling for mA and Voltage inputs through keyboard. |
| Alarm Output ( Optional ) | 1 or 2 common alarm relay output contact rating 230 VAC1 Amp.Confirm relay logic at the time of ordering. |
| Display Update Rate | Display Update rate and Display scroll mode programable through keyboard. |
Key Features
- Ruggedised, State-of-the-art Micro-controller based system.
- Horizontal or Vertical version as per your panel design
- Universal input mA / RTD / Volt / Thermocouples for each channel (factory set).
- Control Output for each channel, indication on front.
Product Description
Falcon 1600, 4 to 16-channel process scanner is a highly versatile and economical module having Analog Inputs with RS485 / Ethernet port for online communication. Process scanner is an ideal solution for SCADA applications in Process Industries. Falcon 1600 can be used along with PLC thus reducing project costs substantially. Analog input to Falcon 1600 can be mA / RTD (PT100, 3 wire) / Thermocouple or Voltage different for each channel. The Alarm / Control status of each channel is indicated on the front LEDs. Serial port RS485 - 2 wire with Modbus RTU protocol or Ethernet with MODBUS TCP is provided. This feature makes Falcon compatible with all the standard SCADA software and PLCs used in Industry. Internal relay output 1 or 2 for common alarm. External relay output 8 or 16 for Individual alarm / Alarm & Trip / Control. Ethernet communication facility with MODBUS TCP protocol.
- User configurable span for mA / Volt inputs.
- Communication on isolated RS485 / Ethernet port with MODBUS / MODBUS TCP protocol.
- Ideal for SCADA applications
- Flameproof enclosure - Optional.
Control Output ( Optional ):8 or 16 nos external relay outputs used as a) 1 Relay per channel with Alarm / Control logic b) 2 Relay per channel (max 8 channels) with alarm-trip logic. External relays can be operated from SCADA also. Confirm relay logic at the time of ordering
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Falcon 1600 supports a maximum of 16 channels, configurable in steps of 4 channels.
It can accept RTD Pt100 (3 wire), mA (0-20 mA, 4-20 mA), thermocouples (JKRSTBE), and voltage inputs (0-1 VDC and 0-4 VDC) for each channel, with combinations set at the factory.
The accuracy of the measurements is 0.5% of FSR with a resolution of 1°C for cold junction compensation (CJC).
The scan rate is 125 milliseconds per channel, allowing for 16 channels to be scanned in 2 seconds.
It features a 7-segment red LED display that shows a 2-digit channel number and a 5-digit process value with a sign.
Communication is facilitated through an optically isolated RS485 2-wire port with MODBUS RTU protocol, and an optional Ethernet port with MODBUS TCP.
The supply requirements are 230 VAC or 110 VAC ±10% at 50 Hz.
The cabinet dimensions are available in two configurations: horizontal (96 x 192 mm) and vertical (192 x 96 mm), with a depth of 195 mm.
The device offers optional alarm outputs with 1 or 2 common alarm relay outputs, rated at 230 VAC, 1 Amp.
The resolution is 12 bits, with specific resolutions of 0.1°C for RTD PT100, 1°C for thermocouples, 0.001 V for voltage, and 0.01 mA for current inputs.
The Falcon 1600 can be mounted in either a horizontal or vertical orientation, depending on the panel design.
Scaling for mA and voltage inputs can be configured through the keyboard on the device.
