ABB Residual Current Circuit Breaker with Overload Protection, 40A Current Rating, 4-Pole, 30 mA Trip 2CSR254101R1407

ABB 2CSR254101R1407 Residual Current Circuit Breaker with overload protection is designed for protection against overload, short-circuits, and earth leakage currents. It offers a rated current of 40A with a 4-pole configuration and trip sensitivity of 30 mA, ensuring comprehensive electrical safety.

This DS200 series device supports 400V AC rated voltage and employs a Type A earth leakage protection mechanism. It uses an instantaneous tripping characteristic (Type K) for rapid fault detection and disconnection, enhancing protection in residential and industrial environments.

The circuit breaker's compact dimensions (105 mm width, 93 mm height, 69 mm depth) facilitate integration into distribution boards where space is a consideration. It features a lever reset actuator for manual resetting after tripping events.

Certified to IEC/EN 61009-1 and IEC/EN 60947-2 standards, the device offers reliable breaking capacity of 10kA, providing robust safety against electrical faults. The neutral terminal design supports easy and secure wiring.

Typical industrial applications include residential buildings, commercial facilities, and automation systems requiring reliable overload and earth fault protection. Set your facility's electrical safety standards with ABB's trusted DS200 RCBO model 2CSR254101R1407, ensuring durable and efficient circuit protection.

Protects against overload and short-circuit currents effectively. Provides earth leakage protection sensitive to 30 mA for user safety. Rated for 400V AC voltage operation suitable for residential and industrial applications.

Instantaneous tripping characteristic ensures quick fault response. Complies with IEC/EN 61009-1 and IEC/EN 60947-2 standards. Features lever reset actuator mechanism for easy manual override. Compact dimensions of 105 mm width, 93 mm height, and 69 mm depth for space-saving installations.

Breaking capacity of 10kA supports robust short circuit protection. Explore more electrical protection solutions within the ABB product range on EnvMart for your industrial, residential, and commercial needs.
