XP Power IEC Filter 264V AC 1A Screw Mount with Faston Termination FCSS01SFR

Free Delivery in India | Lowest Global Shipping Charges

XP Power IEC Filter 264V AC 1A Screw Mount with Faston Termination FCSS01SFR

Name: XP Power IEC Filter 264V AC 1A Screw Mount with Faston Termination FCSS01SFR
Brand: XP Power
SKU: 266136
Price: 20.22 USD
Availability: InStock



Category IEC Filter Brand XP Power Condition New

Specifications

Country of Origin	China
Voltage	264V ac
Brand	XP Power
Current	1A
Height	34mm
Model	FCSS01SFR
Depth	62mm
Width	44mm
Mount Type	Screw
Operating Frequency	400Hz
Termination Type	Faston
Maximum Operating Temperature	110°C
Minimum Operating Temperature	-40°C
Contact Gender	Male
Connector Gender	Male
Fuse Size	5 x 20 mm
Number of Fuses	1

Key Features

The filter includes a front accessible single fuse holder with a 5 x 20 mm fuse size for protection.
It features a shielded metal body design ensuring excellent electromagnetic interference attenuation.
Screw mount installation with male Faston terminals provides secure and easy connectivity.
The operating temperature range spans from -40°C to 110°C, suitable for harsh environments.
Compact dimensions with 34mm height, 44mm width, and 62mm depth make it convenient for integration.
Constructed for Class I appliances, fitted with a bleed resistor for safe discharge of filter capacitors.
Operates at 400Hz frequency with reliable contact and termination performance.
Manufactured in China and designed for durability with a three-year warranty.

Product Description

XP Power FCSS01SFR IEC Filter is a compact, screw-mounted EMI filter designed for mains-powered information technology equipment (ITE). It operates at a voltage of 264V AC and a current rating of 1A, providing effective attenuation of conducted electromagnetic interference from the mains supply.

The unit features a male connector with faston terminals and a front-accessible single fuse holder compatible with 5 x 20 mm fuses to ensure circuit protection. The shielded metal body offers robust protection against external interference and reduces emissions from the equipment back to the mains.

Constructed for Class I appliances, the filter includes a bleed resistor that safely discharges filter capacitors upon power disconnection, enhancing user safety. Its operating temperature range of -40°C to 110°C allows reliable function under varying environmental conditions.

The screw mounting type and compact size (34mm height, 44mm width, and 62mm depth) allow ease of installation in tight spaces. The device functions optimally at an operating frequency of 400Hz, making it suitable for industrial and commercial electronics applications.

This IEC filter is ideal for reducing EMI in laboratory instruments, industrial machines, HVAC systems, and other electrical equipment where EMI compliance is critical. It ensures enhanced performance and longer equipment life by minimizing electronic noise.

The filter includes a front accessible single fuse holder with a 5 x 20 mm fuse size for reliable protection. Shielded metal body construction for excellent EMI attenuation in a compact design. Screw mount type with male Faston terminals for secure and easy installation.

Wide operating temperature range ensures durability in varied conditions. Equipped with bleed resistor to safely discharge capacitors after power off. Suitable for Class I electrical appliances and ITE equipment. Designed for operation at 264V AC, 1A current, and 400Hz frequency.

Compact dimensions allow integration in space-constrained systems. Manufactured in China with a reliability warranty of three years. Explore EnvMart’s wide range of high-quality electronic components including IEC Filters designed for optimal power quality and EMI reduction.
