ABB Residual Current Circuit Breaker with Overload Protection, 10A Current Rating, 1-Pole, 30 mA Trip 2CSR245041R1104

ABB 2CSR245041R1104 Residual Current Circuit Breaker with Overload Protection is a high-quality electrical safety device designed for installation in single-phase distribution systems operating at 240V AC. It combines overload and earth leakage protections, ensuring comprehensive circuit safeguarding against overload currents, short circuits, and earth faults with trip sensitivity of 30 mA. This 1-pole device features a Type C tripping characteristic which is ideal for circuits with moderate transient current surges, commonly encountered in residential and commercial environments.

The DS201 series device integrates reliable multi-functional protection compliant with international standards IEC 61009-1 and IEC 61009-2-1, as well as EN 61009-1 and EN 61009-2-1, ensuring both safety and regulatory compliance. It is constructed to protect users against indirect and direct electric contact hazards by quickly disconnecting supply in the event of earth leakage fault.

Its compact form factor of 85 mm height, 80 mm depth, and 35 mm width allows fitting into two-modules space in distribution boards, with provisions for neutral position on the left side to accommodate various wiring configurations. The device’s breaking capacity of 4.5 kA ensures it can safely interrupt fault currents without damage.

This ABB RCBO is suitable for residential, industrial, commercial buildings, and other applications requiring reliable earth leakage and overload protection combined in a single compact unit. Its robust design and compliance make it an essential component for modern electrical safety installations, contributing to the prevention of electrical accidents and fire hazards.

Rated current of 10 amperes ensures adequate protection for standard residential and commercial circuits. Single-pole design provides compact installation in electrical panels. Trip sensitivity of 30 milliamperes detects earth leakage currents promptly.

Type C tripping characteristic suitable for protecting circuits with moderate inrush currents. Operates at a rated AC voltage of 240 volts to match common power supplies. Breaking capacity of 4.5 kiloamperes withstands high fault currents safely.

Complies with IEC and EN standards for performance and safety. Compact dimensions of 85mm height, 80mm depth, and 35mm width allow efficient panel space usage. Earth leakage protection type AC safeguards against alternating current leakage faults.
