Siemens Residual Current Circuit Breaker with Overload Protection 6A Current Rating 2-Pole 30 mA Trip 5SV1316-7KK06

Siemens 5SV1316-7KK06 Residual Current Circuit Breaker with Overload Protection is a 2-pole device designed to safeguard electrical circuits by instantly disconnecting power in case of earth leakage, overload, or short circuit faults. With a rated current of 6A and trip sensitivity of 30 mA, this SENTRON series RCBO provides precise protection suitable for industrial and commercial electrical installations including automated manufacturing, robotics systems, and electrical panels.

The device features a compact construction with dimensions 17.6mm wide, 90mm height, and 77mm depth, allowing efficient use of space on DIN rail mounts. It is equipped with screw terminals that ensure firm conductor connection even in vibration-prone environments. Designed to operate reliably with a mechanical lifespan of up to 10,000 cycles, it guarantees durability and long service life.

The breaker operates at a rated AC voltage of 195V and carries a breaking capacity of 6 kA, adhering to CE standards. Its Type C tripping characteristic and Type A earth leakage protection are optimized for a wide range of industrial applications. The IP20 rated housing protects against intrusion of objects larger than 12mm when installed correctly.

Furthermore, the RCBO supports a broad temperature range from -25 degrees Celsius to +45 degrees Celsius, allowing it to function reliably in diverse environmental conditions. Its low power loss of 0.6W ensures energy efficiency during operation, helping reduce overall energy consumption.

The product is manufactured in Romania and is part of Siemens' commitment to sustainability with claims of concentrated design, extended product service life, and low carbon manufacturing processes.

Protects against earth leakage, overcurrent, and short circuits to ensure electrical safety. Compact, space-saving design suitable for DIN rail mounting. High reliability with a mechanical lifespan up to 10,000 cycles. Screw terminals provide secure, vibration-resistant connections.

Wide operating temperature range from -25°C to +45°C. Complies with CE standards and features a 6 kA breaking capacity. Low power loss of 0.6W supports energy-efficient use. Manufactured in Romania with sustainable production claims.

This Siemens RCBO is ideal for industrial, commercial, electrical panel, and automation system safety applications. Discover more circuit protection solutions in the Electronics & Electricals category at EnvMart.
