NSK Linear Guide Block NAH25ANCE01PCZ N Series Compact Linear Carriage 79mm x 48mm, 26800 N Dynamic Load NAH25ANCE01PCZ
Specifications
| Country of Origin | India |
|---|---|
| Brand | NSK |
| Model | NAH25ANCE01PCZ |
| Series | N |
| Standards/Approvals | ISO14728-1, ISO14728-2 |
| Static Load Rating | 46000N |
| Dynamic Load Rating | 26800N |
| Carriage Length | 79mm |
| Carriage Width | 48mm |
| NSK Guide Block LAH25ANZ, LHBrand | NSK |
| HSR-R linear guide block,83L x 48WmmBrand | THK |
Key Features
- The guide block has a carriage length of 79mm and carriage width of 48mm.
- Offers a dynamic load rating of 26800 N for enhanced performance and durability.
- Static load rating is 46000 N ensuring reliable operation under load.
- Compliant with ISO14728-1 and ISO14728-2 standards for quality and safety.
- Incorporates an improved groove design to double life expectancy and reduce surface pressure.
- Redesigned ball recirculation path minimizes noise and increases suitability for high-speed applications.
- Compatible with NSK's K1 lubrication system for long-term maintenance-free service.
- Ideal for machine tools, robotics, automotive production lines, semiconductor manufacturing, and automation systems.
Product Description
NSK NAH25ANCE01PCZ linear guide block is a precision mechanical component designed as part of the N Series compact linear carriages. This guide block features a carriage length of 79mm, a width of 48mm, and supports a dynamic load rating of 26800 N and a static load rating of 46000 N, making it suitable for demanding industrial applications.
The N Series represents NSK's updated version of their linear motion technology, incorporating a redesigned groove that doubles the life expectancy by increasing the contact area between the ball and rail slide. This enhancement disperses the load more effectively and reduces surface pressure, significantly boosting maintenance intervals and overall productivity.
The redesigned ball recirculation path not only improves the suitability for high-speed operations but also reduces operational noise by up to 3 dB, enhancing performance in sensitive environments. This guide block maintains installation compatibility with previous LS and LH series, allowing seamless integration with existing systems.
NSK has also introduced their proprietary K1 lubrication system, which uses a unique blend of 70% mineral oil and 30% polyolefin resin to ensure long-term, maintenance-free operation.
Typical industrial applications include machine tools, robotics, semiconductor manufacturing, automotive production lines, CT scanners, measuring instruments, automation systems, and train platform doors, reflecting the versatility and robustness of this guide block.
The guide block carries a carriage length of 79mm and carriage width of 48mm. Features dynamic load capacity of 26800 N and static load capacity of 46000 N. Complies with ISO14728-1 and ISO14728-2 quality standards. Groove redesign extends service life and increases load distribution.
Enhanced ball recirculation reduces noise and supports high-speed use. K1 lubrication system provides maintenance-free reliability. Compatible with existing LS and LH series dimensions. Suitable for various industrial automation and production environments.
Discover the full range of NSK Linear Guide Blocks and compatible components within EnvMart's Industrial Tools & Equipment category for Mechanical Machinery & Spares.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The dynamic load rating of this linear guide block is 26800 N.
This guide block has a carriage length of 79mm and a carriage width of 48mm.
The static load rating for the NSK NAH25ANCE01PCZ is 46000 N.
It complies with ISO14728-1 and ISO14728-2 standards for quality and safety.
This model is compatible with NSK's K1 lubrication system for long-term maintenance-free service.
The redesigned groove increases the contact area between the ball and rail slide, doubling the life expectancy and reducing surface pressure.
It is suitable for machine tools, robotics, automotive production lines, semiconductor manufacturing, and automation systems.
The redesigned ball recirculation path minimizes noise and enhances suitability for high-speed applications, reducing operational noise by up to 3 dB.
The country of origin for this guide block is India.
Yes, it maintains installation compatibility with previous LS and LH series, allowing for seamless integration.
The improved load distribution enhances maintenance intervals and overall productivity by dispersing the load more effectively.
The weight of the NSK NAH25ANCE01PCZ guide block is not specified in the provided data.
