RS PRO 6491B Series Blue Hook Up Wire 7/1.35 mm Core Strands 50 m Thermoplastic Polyolefin UK Origin 185-3947

RS PRO 185-3947 Hook Up Wire from the 6491B Series is a high-quality electrical wire designed with 7 copper strands of 1.35 mm diameter each, encased in a thermoplastic polyolefin blue jacket. This single-core hook-up wire is 50 meters in length, providing ample cable for various industrial and commercial electrical wiring applications.

The cable is designed to withstand operating temperatures ranging from -15°C to 90°C, suited for rigorous environments. Its insulation exhibits low smoke, halogen-free properties ensuring enhanced safety in case of fire, making it ideal for installations where smoke and toxic gas emissions are critical concerns.

Rated for voltages up to 450 volts DC and 750 volts AC, the wire supports both control gear and switchgear fixed installations. The 7-strand copper conductor facilitates excellent electrical conductivity while maintaining flexibility needed for conduit installations.

This conduit-type cable conforms to BS EN 50525-3-41:2011 Clause 4.1 standard, assuring compliance with current safety and quality regulations. It is intended for surface mounting or embedding in closed systems such as conduits to protect wiring runs.

The insulation wall thickness is 1 mm, contributing to the durability of the cable in demanding electrical setups. Its outside diameter measures approximately 7 mm, maintaining a compact form factor suitable for various wiring channels.

Blue jacket colour for easy identification in wiring systems. Consists of 7 strands of 1.35 mm diameter copper core wires. Cable length of 50 meters suitable for medium scale wiring tasks. Thermoplastic polyolefin jacket offers low smoke and halogen-free fire behaviour.

Designed to operate in temperatures from -15°C up to 90°C. Rated for 450V DC and 750V AC voltage applications. Meets BS EN 50525-3-41:2011 Clause 4.1 standards for conduit cables. Suitable for installation in surface mount or embedded conduits.

Conforms to low smoke, halogen-free thermosetting insulation safety standards.

This product is ideal for industrial, commercial electrical installations, control gear wiring, and switchgear applications where safety and performance are paramount. It is manufactured in the United Kingdom, ensuring adherence to high standards and quality control.
