ABB 3-Pole Base Isolator Switch IP20 32A 75 kW OTDC32F3 1SCA121459R1001
Specifications
| Country of Origin | India |
|---|---|
| Brand | ABB |
| Length | 77.6mm |
| Model | IP20 |
| Depth | 77.6mm |
| IP Rating | IP20 |
| Width | 52.5mm |
| Mount Type | Base |
| Series | OTDC32F3 |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | 0°C |
| Switching Current | 32A |
| Terminal type | Screw |
| Handle Colour | Black |
| Number of Poles | 3 |
| Standards/Approvals | IEC, UL |
| Switching DC Voltage | 1000V dc |
| Switching AC Voltage | 415V ac |
| Switching Power | 75kW |
| ABB 2-Pole Base Isolator Switch -, IP20, 16A, 75 kWBrand | ABB |
| ABB 3-Pole Surface Isolator Switch -, IP20, 25A, 7.5 kWBrand | ABB |
Key Features
- Designed for base mounting with a compact form factor.
- Rated IP20 for protection against solid objects exceeding 12.5 mm.
- Equipped with secure screw terminal connections suitable for cables between 2.5 to 16 mm².
- Supports switching voltages up to 1000V dc and 415V ac.
- Complies with IEC and UL standards for safety and performance.
- Operates effectively between 0°C and 60°C ambient temperatures.
- Single throw, 3-pole switch configuration.
- Black handle color for clear operational visibility.
Product Description
ABB OTDC32F3 1SCA121459R1001 3-Pole Base Isolator Switch is a robust electrical device designed to provide safe and effective isolation in specialized electrical systems. It supports a maximum switching current of 32A with a power rating of 75 kW, making it suitable for moderate to high load applications.
This switch features a base mounting design enabling straightforward installation on various surfaces and panels. The IP20 rating ensures protection against solid foreign objects larger than 12.5 mm, providing adequate safety in controlled environments.
The switch supports both DC and AC voltages, with maximum switching capacities of 1000V dc and 415V ac respectively. Its screw terminal connections guarantee secure and stable wiring for cable cross-sections ranging from 2.5 to 16 mm², accommodating typical industrial cabling setups.
Constructed to operate reliably in ambient temperatures from 0°C up to 60°C, this device complies with IEC and UL standards, ensuring a high level of safety and quality certification.
Ideal for photovoltaic systems, industrial control panels, and circuits with resistive loads that require reliable isolation, the 3-pole switch design provides single-throw operational simplicity with a visually distinct black handle.
Base mounting configuration for ease of installation. Rated IP20 for dust ingress protection. Screw terminals for secure wiring connections. Supports 32A switching current and 75 kW power. Switching voltage: up to 1000V dc and 415V ac.
Ambient operating temperature between 0°C and 60°C. Complies with IEC and UL standards. Compact dimensions: 77.6mm (L) x 52.5mm (W) x 77.6mm (D). Ideal for photovoltaic and industrial control panel applications.
This ABB isolator switch is engineered to provide safe electrical isolation and is suitable for various industrial and solar energy management applications. EnvMart customers looking for a high-quality, reliable Isolator Switch will find this model meets rigorous performance and safety requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum switching current for this model is 32A.
This unit has dimensions of 77.6mm in length, 52.5mm in width, and 77.6mm in depth.
The power rating of this isolator switch is 75 kW.
It features a base mounting design for straightforward installation on various surfaces and panels.
This model supports switching voltages up to 1000V dc and 415V ac.
The switch has an IP20 rating, which provides protection against solid objects larger than 12.5 mm.
It operates effectively between ambient temperatures of 0°C and 60°C.
It is equipped with screw terminal connections suitable for cables ranging from 2.5 to 16 mm².
This model complies with IEC and UL standards for safety and performance.
This isolator switch features a 3-pole configuration.
The handle color of this unit is black, providing clear operational visibility.
It is ideal for photovoltaic systems, industrial control panels, and circuits with resistive loads that require reliable isolation.
