ABB Residual Current Circuit Breaker with Overload Protection 13A Current Rating 1-Pole 2CSA275103R1134 DS-ARC1 M C13 A30

ABB 2CSA275103R1134 DS-ARC1 M C13 A30 Residual Current Circuit Breaker with Overload Protection is engineered to provide comprehensive protection for electrical installations in residential, commercial, and light industrial applications. It offers a rated current of 13A, single-pole design, and a trip sensitivity of 30mA, making it suitable for detecting earth leakage currents effectively.

Part of the DS-ARC1 series within the System Pro M Compact range, this device provides integrated arc fault detection and overcurrent protection with a robust breaking capacity of 10kA. The compact design with a three-module width eases installation and saves panel space.

This circuit breaker supports direct mounting on DIN rails and features screw terminals for secure cable connections. The thermal magnetic tripping mechanism ensures prompt response under overload and short circuit conditions, while the Type C characteristic caters to moderate inductive loads such as motors and transformers.

Additional design benefits include supply flexibility with double slots allowing cable and busbar connections from both top and bottom, as well as inclusion of LED indicators and two test buttons to verify the operating status of Arc Fault Detection Device (AFDD) and Residual Current Device (RCD) functions.

Manufactured in Italy, the breaker complies with IEC safety standards and RoHS environmental restrictions, ensuring reliable, safe, and environmentally friendly operation. Compact 1P+N module width design. High breaking capacity of 10kA for fault current interruptions.

Thermal magnetic tripping with Type C characteristic. Easy DIN rail mounting and screw terminal connections. LED indicators for fault and operation status monitoring. Dual test buttons for testing AFDD and RCD functions.

Flexible supply connection from top or bottom. Compliance with IEC and RoHS standards. Manufactured in Italy ensuring quality and reliability.

This Residual Current Circuit Breaker is ideal for use in electrical panels in industrial, commercial, and residential environments where protection against electric shock, overloads, short circuits, and arc faults is mandatory. It is compatible with System Pro M Compact accessories for streamlined integration. Browse EnvMart's extensive range of circuit breakers and protective devices for your electrical safety needs.
