ABB Residual Current Circuit Breaker with Overload Protection 6A Current Rating 1-Pole 30mA Trip Sensitivity DS-ARC1 M C6 A30



Category Residual Current Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	System Pro M Compact
Brand	ABB
Height	85mm
Model	DS-ARC1 M C6 A30
Depth	85mm
Width	52.5mm
Mount Type	DIN Rail
Current Rating	6A
Series	DS-ARC1
Terminal type	Screw
Breaking Capacity	10kA
Number of Poles	1
Standards/Approvals	RoHS, IEC
Rated AC Voltage	240V ac
Tripping Characteristics	Type C
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Toggle Switch
Trip Sensitivity	30mA
Earth Leakage Protection Type	Type A
Supply possible both from top and bottom side	double slots available for connection with cables and busbars

Key Features

Integrates residual current circuit breaker with overcurrent protection in a compact 3-module width design.
Provides complete protection against arc faults, overvoltages, overcurrent, and earth fault currents.
Compatible with System pro M compact® busbars allowing easy cross-wiring and installation.
Double slots allow supply from both top and bottom for versatile connection with cables or busbars.
Features LED indicators for straightforward network troubleshooting.
Includes two test buttons to verify proper AFDD and RCD operation.
Equipped with continuous internal self-test to ensure ongoing reliability.
Mounts easily on DIN rail with screw terminal type connectors.

Product Description

ABB DS-ARC1 M C6 A30 residual current circuit breaker with overload protection combines advanced 6A current rating, 1-pole configuration, and 30mA trip sensitivity to safeguard electrical installations in residential, commercial, and industrial applications.

This device integrates arc fault detection device (AFDD) capabilities and residual current circuit breaker with overcurrent protection (RCBO) within a compact 3-module width form factor. Its design offers comprehensive protection against arc faults, overvoltages, overcurrent, and earth fault currents ensuring enhanced safety and compliance.

Installation is simplified by compatibility with System pro M compact® accessories and busbars, supporting easy cross-wiring without extra cables. The breaker supports supply connections from both top and bottom through double slots, providing flexibility in cable management.

LED indicators facilitate easy troubleshooting of network issues while two dedicated test buttons enable verification of AFDD and residual current device (RCD) functionality. The continuous internal self-test enhances safety by monitoring device operation uninterruptedly.

Constructed with a thermal magnetic tripping mechanism and toggle switch reset actuator, the breaker features screw terminals and DIN rail mounting for secure and reliable installation. Breaking capacity is rated at 10 kA at 240VAC, meeting robust industry standards RoHS and IEC.

Complete arc fault detection with integrated residual current and overcurrent protection. Compact 3-module width suited for space-saving distribution panels. Flexible supply options with top and bottom connections. Intuitive LED troubleshooting and test button verification.

Thermal magnetic tripping mechanism with Type C characteristics. High breaking capacity of 10 kA ensures protection under fault conditions. Complies with RoHS and IEC standards ensuring quality and safety. Manufactured in Italy, ensuring premium build and reliability.

This ABB Residual Current Circuit Breaker is ideal for applications in electrical distribution boards in residential, commercial, HVAC, and industrial sectors. It enhances circuit protection, operator safety, and system reliability.
