ABB Residual Current Circuit Breaker with Overload Protection 6A Current Rating 1-Pole 30 2CSA275103R1065 DS-ARC1 M B6 A30

ABB 2CSA275103R1065 DS-ARC1 M B6 A30 Residual Current Circuit Breaker with Overload Protection is engineered to provide comprehensive protection against electrical faults including arc faults, overcurrents, and earth leakage currents. With a current rating of 6 amperes and trip sensitivity of 30 mA, this device ensures sensitive and rapid disconnection under fault conditions, enhancing safety in residential, commercial, and industrial electrical systems.

This 1-pole breaker belongs to the DS-ARC1 series within the System pro M Compact range, featuring a compact three-module width design that integrates arc fault detection with residual current protection. Its thermal magnetic tripping mechanism enables robust overload and short circuit response, while the Type B tripping characteristic allows for detection of AC, pulsating DC and smooth DC residual currents.

The unit is constructed for easy DIN rail mounting and supports screw terminal connections, facilitating secure and efficient installation. Its dual supply capability with connection possible from both top and bottom using double slots ensures flexible cabling and compatibility with System pro M compact busbars without additional wiring.

Built to meet IEC and RoHS standards, this breaker assures quality and environmental compliance. The compact size (85mm height x 85mm depth x 52.5mm width) fits standard distribution panels. Additional features include a toggle switch for manual reset and LED indicators for easy troubleshooting.

Ideal for use in industrial, commercial, and residential electrical distribution panels, this circuit breaker safeguards circuits from overcurrents and earth fault currents, ensuring operational safety and compliance with electrical safety regulations.

Rated current is 6 amperes for precise circuit control. Single-pole configuration ideal for compact electrical installations. Type B tripping characteristic ensures versatile earth leakage protection. Equipped with thermal magnetic tripping mechanism for overload safety.

Mounts easily on DIN rail systems for flexible application. Rated for 240V AC supply voltage compatible with standard electrical systems. Breaking capacity of 10kA provides high short-circuit protection. Compact dimensions with 85 mm height, 85 mm depth, and 52.5 mm width optimize panel space.

Includes toggle switch reset actuator for straightforward operation. Designed with screw-type terminals for secure wiring connections. LED indicators facilitate quick troubleshooting and system diagnostics. Made in Italy with compliance to IEC and RoHS standards.
