Microchip 8 bit PIC PIC10F Microcontroller 8 MHz FLASH 6-Pin SOT-23 PIC10F220T-I/OT
Specifications
| Country of Origin | Thailand |
|---|---|
| Brand | Microchip |
| Height | 1.3mm |
| Length | 3.1mm |
| Model | PIC10F220T-I/OT |
| Width | 1.8mm |
| Mount Type | Surface |
| Series | PIC10F |
| Maximum Operating Temperature | 85°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Ram size | 16bit |
| Interface Type | EUSART |
| Pin Count | 6 |
| Maximum Supply Voltage | 5.5V |
| Maximum Power Dissipation Pd | 800mW |
| Minimum Supply Voltage | 1.8V |
| Device Core | PIC |
| Program Memory Size | 0.38kB |
| Maximum Clock Frequency | 8MHz |
| Number of Programmable I/Os | 33 |
| Analogue Comparators | 2 |
| Number of Timers | 1 |
| Instruction Set Architecture | RISC |
| ADCs | 2 x 8 Bit |
| Program Memory Type | FLASH |
| DACs | 1 x 5 Bit |
| Microchip, 8bit PIC, PIC10F Microcontroller, 8MHz, 512 Flash, 6-Pin SOT-23Brand | Microchip |
Key Features
- Operates at a maximum clock frequency of 8 MHz for reliable performance.
- Equipped with 0.38 kB of FLASH program memory for versatile code storage.
- Features 33 programmable input/output pins supporting extensive device interfacing.
- Includes 2 x 8-bit ADCs for precise analog signal conversion and 2 analog comparators.
- Compact 6-pin SOT-23 surface mount package measuring 3.1 x 1.8 x 1.3 mm suitable for space-constrained designs.
- Operates over a wide voltage range from 1.8 V to 5.5 V, enhancing power flexibility.
- Maximum power dissipation rated at 800 mW ensures efficient energy usage.
- RISC architecture providing up to 5 million instructions per second (MIPs) optimized for baseline control tasks.
Product Description
Microchip PIC10F220T-I/OT is an 8-bit baseline PIC Microcontroller featuring a maximum clock frequency of 8 MHz and 0.38 kB of FLASH memory. Its compact 6-pin SOT-23 package is ideal for applications where space and cost are critical. The device includes 33 programmable input/output pins and is built with RISC architecture, delivering up to 5 MIPs performance.
Operating across a supply voltage range of 1.8 V to 5.5 V and a temperature range of -40°C to 85°C, this microcontroller supports demanding environmental conditions found in various industrial and commercial electronics.
It features 16-bit RAM size, 2 x 8-bit ADCs, one 5-bit DAC, and two analog comparators, allowing advanced analog and digital interfacing in embedded systems. The 800 mW power dissipation rating helps maintain low power consumption while providing steady operation.
This microcontroller is surface-mounted with a small 3.1 mm length, 1.8 mm width, and 1.3 mm height, making it suitable for compact PCB layouts. Its minimal pin count and efficient design support applications in sensor interfaces, simple control systems, and consumer electronics requiring cost-effective microcontroller solutions.
The PIC10F220T-I/OT device’s RISC architecture enhances execution efficiency without interrupt overhead, making it suitable for basic control operations. Its functionality can also be expanded via external development tools using ICD interface headers.
Operates at up to 8 MHz with 0.38 kB FLASH memory. Includes 33 programmable I/Os with multiple analog and digital features. Compact and low-profile 6-pin SOT-23 package for miniaturized designs. Wide voltage and temperature range for industrial uses.
Supports embedded control, sensor interfacing, and consumer electronic applications.
This microcontroller is ideal for industrial, laboratory, manufacturing, HVAC, and consumer electronic sectors requiring low-cost, low-power 8-bit microcontrol solutions. Browse similar Microchip Microcontrollers and embedded solutions on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It operates at a maximum clock frequency of 8 MHz.
The program memory size is 0.38 kB of FLASH memory.
This microcontroller includes 33 programmable input/output pins.
It operates over a wide voltage range from 1.8 V to 5.5 V.
The dimensions of the package are 3.1 mm in length, 1.8 mm in width, and 1.3 mm in height.
The maximum power dissipation is rated at 800 mW.
It operates within a temperature range of -40°C to 85°C.
It is built on a RISC architecture, providing up to 5 million instructions per second (MIPs).
It supports EUSART as its interface type.
The country of origin for this microcontroller is Thailand.
