Microchip 8-bit PIC Microcontroller PIC12F508-E/SN 0.75kB FLASH 4 MHz SOIC 8-Pin Surface Mount
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Height | 1.5mm |
| Length | 8.65mm |
| Model | PIC12F508-E/SN |
| Width | 3.9mm |
| Mount Type | Surface |
| Series | PIC12F |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Ram size | 25bit |
| Interface Type | SPI |
| Pin Count | 8 |
| Automotive Standard | ISO/TS 16949 |
| Maximum Supply Voltage | 5.5V |
| Maximum Power Dissipation Pd | 800mW |
| Minimum Supply Voltage | 1.8V |
| Device Core | PIC |
| Program Memory Size | 0.75kB |
| Maximum Clock Frequency | 4MHz |
| Number of Programmable I/Os | 18 |
| Analogue Comparators | 2 |
| Number of Timers | 1 |
| Instruction Set Architecture | RISC |
| ADCs | 0 bit |
| Program Memory Type | FLASH |
Key Features
- Built on PIC architecture with RISC instruction set for efficient processing.
- Operates at a maximum clock frequency of 4 MHz with 0.75kB program memory.
- Equipped with 18 programmable I/O pins and 25 bits of RAM.
- Supports In-Circuit Serial Programming (ICSP) and In-Circuit Debugging (ICD).
- Wide operating temperature range from -40°C to 125°C for diverse applications.
- Low power consumption with maximum power dissipation of 800mW.
- Compact SOIC package measuring 8.65mm length, 3.9mm width, and 1.5mm height.
- Features two analogue comparators and one 8-bit timer.
Product Description
Microchip PIC12F508-E/SN is an 8-bit microcontroller designed with the PIC12F series core architecture featuring a compact 8-pin SOIC surface mount package suitable for space-constrained electronics applications. The microcontroller operates at a maximum clock speed of 4 MHz utilizing an internal RC oscillator, offering up to 0.75kB of flash program memory and 25-bit RAM, suitable for embedded control systems and electronic designs.
It features 18 programmable input/output pins that allow flexible interfacing options and supports SPI communication, facilitating integration in industrial, consumer, and automotive electronics. The device incorporates one 8-bit timer and two analogue comparators for event timing and signal comparison tasks. The operating voltage ranges from 1.8V to a maximum of 5.5V, with power dissipation limited to 800mW ensuring low power operation.
Designed for robust operation, the PIC12F508-E/SN microcontroller can operate across a wide temperature range from -40°C to 125°C, making it suitable for harsh environments including automotive and industrial applications compliant with ISO/TS 16949 automotive standards. The instruction set architecture is based on RISC principles, optimizing performance with 33 instructions and a 2-level hardware stack for fast and efficient code execution.
Ideal for applications in industrial automation, consumer electronics, IoT devices, and embedded control, this microcontroller supports In-Circuit Serial Programming (ICSP) and In-Circuit Debugging (ICD), enhancing development productivity and flexibility in firmware updates. The compact dimensions of 8.65mm length, 3.9mm width, and 1.5mm height support PCB space optimization.
Built on PIC12F core with RISC instruction set. 0.75kB Flash memory with SPI interface support. Up to 18 programmable I/O pins in an 8-pin SOIC package. Operating temperature range from -40°C to 125°C with ISO/TS 16949 compliance.
Low power dissipation at 800mW maximum. Supports ICSP and ICD for programming and debugging. Compact form factor measuring 8.65 x 3.9 x 1.5 mm. Two analog comparators and one 8-bit timer integrated. Internal RC oscillator with ±1% accuracy for stable timing.
Explore Microchip PIC12F508-E/SN microcontrollers in the Microcontrollers category for applications in industrial, automotive, and electronics development projects here at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The PIC12F508-E/SN operates at a maximum clock frequency of 4 MHz.
It features 0.75kB of FLASH program memory.
This model has 18 programmable I/O pins.
The operating temperature range is from -40°C to 125°C.
It comes in an 8-pin SOIC surface mount package.
The maximum supply voltage is 5.5V.
Yes, it supports In-Circuit Serial Programming (ICSP) and In-Circuit Debugging (ICD).
The maximum power dissipation is 800mW.
It is built on the PIC architecture with a RISC instruction set.
The PIC12F508-E/SN includes two analogue comparators.
The height of this model is 1.5mm.
It complies with the ISO/TS 16949 automotive standard.
