ABB Molded Case Circuit Breaker 4-Pole 100A 690V AC 500V DC Breaking Capacity 5kA Fixed 1SDA067460R1 XT1H 160 TMD 100A FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Molded Case Circuit Breaker 4-Pole 100A 690V AC 500V DC Breaking Capacity 5kA Fixed 1SDA067460R1 XT1H 160 TMD 100A FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	130mm
Model	1SDA067460R1 XT1H 160 TMD 100A FF
Depth	70mm
Width	101.6mm
Mount Type	Fixed
Current Rating	100A
Series	1SDA06
Terminal type	Screw
Breaking Capacity	5kA
Number of Poles	4
Standards/Approvals	IEC
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Break Time	Instantaneous
Rated current (In)	100 A In
Rated frequency (f)	50/60 Hz
Rated voltage (Ur)	690 V
Rated impulse withstand voltage (Uimp)	8 kV

Key Features

Rated current of 100 A ensures stable electrical performance.
Supports rated AC voltage of 690 V and rated DC voltage of 500 V.
Designed with thermomagnetic release for precise circuit interruption.
Features screw terminal type for secure and easy connection.
Complies with IEC standards for quality assurance.
Compact dimensions with height of 130 mm, width of 101.6 mm, and depth of 70 mm.
Instantaneous break time enhances safety during overcurrent conditions.
Rated impulse withstand voltage of 8 kV for high voltage stress tolerance.

Product Description

ABB 1SDA067460R1 XT1H 160 TMD 100A FF Molded Case Circuit Breaker is a 4-pole fixed mounting circuit breaker designed to provide reliable protection in industrial and commercial electrical applications. It is rated for 100 A current and capable of interrupting faults up to 5 kA, ensuring safety and system stability.

The device supports a rated AC voltage of 690 V and DC voltage up to 500 V, making it suitable for a variety of alternating and direct current circuit setups. It features a thermomagnetic release mechanism that allows precise overcurrent detection and rapid disconnection to protect circuits.

Connection is facilitated through screw terminals, providing a secure and durable interface. The breaker conforms to IEC standards, underscoring its safety and quality credentials.

With an instantaneous breaking time, the MCCB reacts quickly to abnormal current conditions to avoid equipment damage or fire hazards. The rated impulse withstand voltage of 8 kV ensures that the breaker can withstand high voltage surges without damage.

Its compact dimensions of 130 mm height, 101.6 mm width, and 70 mm depth allow integration even in constrained switchgear layouts. Manufactured in Italy, this breaker meets rigorous quality and reliability standards.

Rated current of 100 A ensures stable electrical performance. Supports rated AC voltage of 690 V and rated DC voltage of 500 V. Designed with thermomagnetic release for precise circuit interruption. Features screw terminal type for secure and easy connection.

Complies with IEC standards for quality assurance. Compact dimensions with height of 130 mm, width of 101.6 mm, and depth of 70 mm. Instantaneous break time enhances safety during overcurrent conditions. Rated impulse withstand voltage of 8 kV for high voltage stress tolerance.

Manufactured in Italy ensuring international quality standards.

This Molded Case Circuit Breaker is ideal for use in industrial, manufacturing, electrical distribution, and commercial applications requiring dependable circuit protection with high breaking capacity and compatibility with both AC and DC systems.
