ABB Molded Case Circuit Breaker 4-Pole 100A 690V AC Breaking Capacity 150 kA Solid State Release XT2L

Free Delivery in India | Lowest Global Shipping Charges

ABB Molded Case Circuit Breaker 4-Pole 100A 690V AC Breaking Capacity 150 kA Solid State Release XT2L



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	XT2L
Brand	ABB
Height	130mm
Model	XT2L
Depth	82.5mm
Width	120mm
Mount Type	Fixed
Current Rating	100A
Series	1SDA06
Terminal type	Fixed
Breaking Capacity	150kA
Number of Poles	4
Standards/Approvals	CE, IEC, RoHS
Rated AC Voltage	690V ac
Better World Claim	Designed for Disassembly
Tripping Mechanism	Solid State
Reset Actuator Type	Lever
Short circuit performance level	L

Key Features

This circuit breaker supports a rated operational voltage of 690V AC.
Equipped with solid state tripping mechanism for reliable protection.
Features a fixed mount and fixed terminal type for secure installation.
Designed with a reset actuator lever for simple manual operation.
Complies with CE, IEC, and RoHS standards, ensuring quality and safety.
Compact dimensions facilitate integration within electrical panels.
Built with Better World principles, designed for easy disassembly and sustainability.
Manufactured in Italy to high industrial standards.

Product Description

ABB XT2L molded case circuit breaker is a 4-pole fixed device designed for industrial and commercial electrical protection applications. It features a 100A current rating with a breaking capacity of 150 kA, suitable for high short-circuit withstand capabilities. The breaker operates at a rated voltage of 690 Volts AC and provides insulation up to 1000 V, ensuring robust performance under demanding electrical conditions.

The tripping mechanism is solid-state with Ekip LSIG technology that offers precise and reliable protection. The circuit breaker is equipped with a lever-type reset actuator for ease of manual control during reset procedures. Fixed mounting and terminal designs support secure, durable installations in switchgear assemblies.

Dimensionally, this device measures 130mm in height, 120mm in width, and 82.5mm in depth, making it compact for various panel configurations. Compliant with CE, IEC, and RoHS standards, the breaker guarantees safety, environmental compliance, and operational integrity. It is part of the ABB XT2L 1SDA06 range, engineered for better sustainability by facilitating designed-for-disassembly and recycling practices.

This circuit breaker is ideal for electrical systems in industrial plants, manufacturing facilities, and commercial buildings where reliable overload and short circuit protection is paramount. Its high breaking capacity ensures system stability and safety during fault conditions, protecting connected equipment and personnel.

This circuit breaker supports a rated operational voltage of 690V AC. Equipped with solid state tripping mechanism for reliable protection. Features a fixed mount and fixed terminal type for secure installation. Designed with a reset actuator lever for simple manual operation.

Complies with CE, IEC, and RoHS standards, ensuring quality and safety. Compact dimensions facilitate integration within electrical panels. Built with Better World principles, designed for easy disassembly and sustainability.

Manufactured in Italy to high industrial standards.

For those requiring high-performance molded case circuit breakers, ABB's XT2L series provides advanced technology combined with durable construction. Explore more items within the Molded Case Circuit Breaker category of EnvMart to find compatible products and accessories.
