Schneider Electric ComPact NSXm Molded Case Circuit Breaker 4-Pole 160A 36kA Breaking Capacity DIN Rail LV426369
Specifications
| Country of Origin | India |
|---|---|
| Range | ComPact |
| Brand | Schneider Electric |
| Height | 137mm |
| Model | LV426369 |
| Depth | 137mm |
| Width | 80mm |
| Mount Type | DIN Rail |
| Current Rating | 160A |
| Series | NSXm |
| Terminal type | Screw |
| Breaking Capacity | 36kA |
| Number of Poles | 4 |
| Standards/Approvals | CCC, CE, EAC, EN, IEC, RoHS |
| Rated AC Voltage | 690V ac |
| Tripping Characteristics | Type D |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
| Mount Hole Size | 4.5 mm |
Key Features
- This circuit breaker has a rated AC voltage of 690 volts.
- It is designed for DIN rail mounting with 4.5 mm mount hole size.
- The terminal type is screw for secure electrical connections.
- It includes a toggle switch reset actuator for easy operation.
- Thermal magnetic tripping mechanism with Type D tripping characteristics provides reliable protection.
- Complies with multiple standards including CCC, CE, EAC, EN, IEC, and RoHS certifications.
Product Description
Schneider Electric LV426369 ComPact NSXm Molded Case Circuit Breaker is a compact and efficient solution designed for industrial and commercial electrical protection applications. This 4-pole circuit breaker supports a current rating of 160A and provides a breaking capacity of 36 kA, ensuring high-performance protection in power distribution systems operating at up to 690 V AC.
The circuit breaker is designed for DIN rail mounting, facilitating simple installation and integration into electrical panels. Its screw-type terminals ensure reliable and secure cable connections, minimizing risks of loose contacts and increasing connection stability.
Dimensions of the device are 137 mm in height, 80 mm in width, and 137 mm in depth, making it suitable for compact electrical enclosures. The toggle switch reset actuator allows quick manual reset after tripping events, optimizing downtime during maintenance.
Equipped with thermal magnetic tripping mechanism and Type D tripping characteristics, this molded case breaker offers both overload and short-circuit protection tailored for industrial electrical circuits.
Rated AC voltage: 690V AC for high voltage applications. Breaking capacity: 36 kA ensuring safe interruption of fault currents. 4-pole design for three-phase and neutral connection protection. Compact NSXm series fitting applications from 16A to 160A.
Complies with safety and quality standards CCC, CE, EAC, EN, IEC, and RoHS. Suitable for use in industrial, manufacturing, commercial, and electrical automation systems. DIN rail mounting supports standard electrical enclosure designs.
This Schneider Electric Molded Case Circuit Breaker is ideal for protecting electrical installations in industrial environments, ensuring reliable circuit interruption and safety. Its compact design combined with integrated earth leakage protection options makes it versatile for various power distribution requirements.
Explore the wide range of Schneider Electric electrical protection devices on EnvMart for your industrial automation and electrical safety solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 160A, making it suitable for various industrial and commercial electrical applications.
It provides a breaking capacity of 36 kA, ensuring safe interruption of fault currents in power distribution systems.
The rated AC voltage for this unit is 690V, which allows it to be used in high voltage applications.
It is designed for DIN rail mounting, facilitating easy installation in standard electrical enclosures.
The dimensions are 137 mm in height, 80 mm in width, and 137 mm in depth, making it compact for various installations.
It features a thermal magnetic tripping mechanism, which provides reliable overload and short-circuit protection.
This unit has screw-type terminals, ensuring secure and reliable electrical connections.
It has Type D tripping characteristics, which are suitable for applications with high inrush currents.
It complies with multiple standards including CCC, CE, EAC, EN, IEC, and RoHS certifications.
The reset actuator is a toggle switch, allowing for easy manual reset after tripping events.
This model is part of the NSXm series, which includes various current ratings from 16A to 160A.
The country of origin for this model is India, indicating its manufacturing location.
