ABB Tmax XT Molded Case Circuit Breaker 4-Pole 25A, Breaking Capacity 65 kA, Fixed, Thermal 1SDA068095R1 XT4N 160 TMD 25A FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Tmax XT Molded Case Circuit Breaker 4-Pole 25A, Breaking Capacity 65 kA, Fixed, Thermal 1SDA068095R1 XT4N 160 TMD 25A FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	160mm
Model	1SDA068095R1 XT4N 160 TMD 25A FF
Depth	82.5mm
Width	140mm
Mount Type	Fixed
Current Rating	25A
Series	Tmax XT
Terminal type	Fixed
Breaking Capacity	65kA
Number of Poles	4
Standards/Approvals	RoHS, CE, IEC
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Better World Claim	Designed for Disassembly
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Lever
Rated current (In)	25 A In
Rated frequency (f)	50/60 Hz
Rated voltage (Ur)	690 V
Rated impulse withstand voltage (Uimp)	8 kV

Key Features

Equipped with thermal magnetic tripping mechanism for precise overload and short circuit protection.
Fixed mounting and terminal type for stable installation and connectivity.
Rated current of 25 amperes with rated uninterrupted current of 160 amps.
Complies with RoHS, CE, and IEC standards ensuring high safety and environmental compliance.
Compact dimensions of 140mm width, 160mm height, and 82.5mm depth suitable for diverse electrical panels.
Designed as a Better World product with features for easy disassembly and sustainability.
Suitable for industrial, commercial, and automation electrical protection applications.

Product Description

ABB 1SDA068095R1 XT4N 160 TMD 25A FF Molded Case Circuit Breaker is a high-performance 4-pole circuit breaker designed to provide reliable electrical protection in industrial and commercial settings. Rated for a current of 25 amperes with a high breaking capacity of 65 kA, this breaker is suitable for both AC (690V) and DC (500V) systems.

Featuring a thermal magnetic tripping mechanism, it offers precise protection against overloads and short circuits. The fixed mounting and terminal configuration ensure secure and stable installation in electrical panels.

With dimensions of 140mm width, 160mm height, and 82.5mm depth, the compact design fits well in a range of applications. The product meets stringent safety and environmental standards including RoHS, CE, and IEC certifications, emphasizing its quality and compliance.

This Better World product is designed for disassembly, supporting sustainability goals in electrical distribution systems. The breaker uses a lever reset actuator for easy operation and has a rated frequency range of 50/60 Hz.

Thermal magnetic tripping mechanism for overload and short circuit protection. Fixed mounting and terminal type for dependable installation. Rated current of 25A with a rated uninterrupted current of 160A ensures strong performance.

Compact dimensions suitable for various electrical panel layouts. Compliance with RoHS, CE, IEC ensures product quality and safety. Better World Claim: Designed for disassembly enhancing sustainability. Ideal for industrial, commercial, and automation electrical protection needs.

This Molded Case Circuit Breaker is ideal for electrical, automation, and manufacturing environments requiring robust circuit protection. For a comprehensive selection of circuit breakers and related products, browse the Electronics & Electricals category at EnvMart.
