ABB Molded Case Circuit Breaker 4-Pole 100A 690V AC 200kA Breaking Capacity Fixed Terminal XT2V 1SDA06 1SDA068025R1

Free Delivery in India | Lowest Global Shipping Charges

ABB Molded Case Circuit Breaker 4-Pole 100A 690V AC 200kA Breaking Capacity Fixed Terminal XT2V 1SDA06 1SDA068025R1



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	XT2V
Brand	ABB
Height	130mm
Model	XT2V
Depth	82.5mm
Width	120mm
Mount Type	Fixed
Current Rating	100A
Series	1SDA06
Terminal type	Fixed
Breaking Capacity	200kA
Number of Poles	4
Standards/Approvals	CE, IEC, RoHS
Rated AC Voltage	690V ac
Better World Claim	Designed for Disassembly
Tripping Mechanism	Solid State
Reset Actuator Type	Lever
Short circuit performance level	V

Key Features

This circuit breaker operates at a rated AC voltage of 690V.
Features a solid state release with Ekip LSIG trip unit for enhanced safety.
It has a fixed mounting and terminal type for secure installation.
The device dimensions are 130mm height, 120mm width, and 82.5mm depth.
Complies with CE, IEC, and RoHS standards ensuring quality and environmental safety.
Equipped with a lever reset actuator for easy operation.
Designed as a Better World product with a focus on disassembly and sustainability.
Short circuit performance level is rated as V for reliability in critical applications.

Product Description

ABB XT2V Molded Case Circuit Breaker 4-Pole 100A 690V AC with a breaking capacity of 200 kA is engineered for industrial and commercial electrical circuit protection. This fixed mounting circuit breaker features fixed terminals ensuring secure, reliable connectivity in demanding environments. The circuit breaker is fitted with a solid state release Ekip LSIG trip unit, providing precise tripping characteristics optimized for protection against overload, short circuits, and faults.

Dimensions of the device are 130mm in height, 120mm in width, and 82.5mm in depth, offering a compact footprint suitable for various panel installations. It complies with CE, IEC, and RoHS certifications, underscoring compliance with international safety and environmental requirements.

The device incorporates a lever reset actuator for simple manual resetting, enhancing user convenience during maintenance or after a trip event. As a Better World product, it is designed for easy disassembly contributing to sustainability and responsible end-of-life management.

This circuit breaker is ideal for applications across electrical distribution, automation, manufacturing, HVAC systems, and industrial processing environments requiring high reliability and safety standards.

This circuit breaker operates at a rated AC voltage of 690V. Features a solid state release with Ekip LSIG trip unit for enhanced safety. It has a fixed mounting and terminal type for secure installation. The device dimensions are 130mm height, 120mm width, and 82.5mm depth.

Complies with CE, IEC, and RoHS standards ensuring quality and environmental safety. Equipped with a lever reset actuator for easy operation. Designed as a Better World product with a focus on disassembly and sustainability.

Short circuit performance level is rated as V for reliability in critical applications.

Explore the comprehensive range of ABB Molded Case Circuit Breakers in the EnvMart catalog for advanced electrical protection solutions tailored to industrial and commercial needs.
