WAGO EPSITRON Electronic Circuit Breaker 1A 24V DIN Rail 787-2861/100-000

The WAGO 787-2861/100-000 EPSITRON Electronic Circuit Breaker is a high-performance protective device designed for automated control systems operating at 24 VDC. With a fixed nominal output current of 1 ampere and a maximum breaking capacity of 15 amps, it ensures robust safeguarding of electrical circuits.

This circuit breaker is compact with dimensions of 94mm length, 6mm width, and 94mm depth, making it suitable for tight installations on standard DIN-35 rails. Its clamp terminal design facilitates secure and reliable wiring connections.

Operating efficiently within a voltage range of 18V to 30V DC, the device adapts its protection response time between 4 milliseconds and 100 seconds, accommodating varying load conditions. Integrated LED indicators provide immediate visual feedback on the circuit breaker status, aiding maintenance and monitoring.

Certified to comply with CE, EAC, EN 61000-6-2, RoHS, and UL 61010-2-201 standards, it meets stringent quality and safety requirements. The breaker performs reliably within industrial temperature limits from -25°C to 70°C, supporting diverse industrial, manufacturing, and automation applications.

Ideal for use in electrical panels for circuit protection, renewable energy systems managing DC loads, and machinery requiring overload safeguarding. Its high efficiency rating of 99% minimizes power loss, enhancing energy savings in complex installations.

Fixed 1A output current guarantees consistent protection. Robust 15A breaking capacity protects electrical equipment from short circuits. Compact design allows installation in limited spaces. DIN Rail mounting simplifies integration in control panels.

LED indicators enable quick status checks. Explore more WAGO Electronic Circuit Breakers for reliable industrial and commercial power management solutions.
