RS PRO Push Button Switch, Momentary, Panel Mount, 16 mm Cutout, SPST, IP67, 36 V dc 175-9148

RS PRO 175-9148 Push Button Switch is a momentary type switch designed for panel mounting applications requiring a 16 mm cutout. It features a single pole single throw (SPST) contact configuration and is rated for IP67 ingress protection, making it waterproof and dust tight. This switch handles a DC voltage of 36 volts and has a switch contact current rating of 2 amperes.

The actuator style is flat, which provides a sleek and ergonomic interface for operators. It uses solder terminals for wiring which ensures secure electrical connections. The switch is rated for operation in a temperature range from -20°C to 70°C, supporting harsh environmental conditions.

Manufactured to meet UL 94 V-0 and UL 94 V-2 standards for flammability, it is suitable for multiple industrial use cases including industrial control instrumentation, medical equipment, security monitoring systems, vehicle peripherals, and audio-visual devices.

The RS PRO metal switches stand out for their lightweight, corrosion resistance, high strength, aesthetic appearance, and effective heat dissipation. Its vandal-resistant features also allow safe use in public settings while ensuring long life expectancy.

Designed for momentary push button operation. IP67 rated ingress protection for water and dust resistance. Panel mount with 16 mm cutout size. SPST contact configuration rated at 2A and 36 V dc. Flat actuator style with solder terminal type.

Operates reliably in temperatures from -20°C to 70°C. UL 94 V-0 and V-2 certified for fire safety. Ideal for industrial, medical, security, and audio-visual applications. Vandal-resistant design suitable for public environments.
