Molex Sherlock Series Straight Through Hole PCB Header, 5 Contacts, 2 mm Pitch, 1 Row, Shrouded 35362-0550

The Molex 35362-0550 Sherlock Series Straight Through Hole PCB Header is a precision-engineered connector designed for reliable wire-to-board applications. It features 5 brass contacts with tin plating arranged in a single row at a 2 mm pitch, ensuring accurate alignment and optimal electrical connection.

The shrouded design prevents misalignment and protects the connectors during assembly. The straight orientation and through-hole mounting make it suitable for various PCB configurations in industrial, electronics manufacturing, and equipment repair contexts.

This PCB header supports a maximum current of 2A and voltage rating up to 125V, making it ideal for low to moderate power applications. The operating temperature range from -40°C to 105°C ensures dependable performance in diverse environmental conditions, including industrial and commercial electronics systems.

The termination style utilizes soldering of pins through the PCB, providing a secure mechanical and electrical connection. The tail pin length of 3.3 mm is designed for effective solder joints, contributing to long-term durability.

The Sherlock connector system includes polarizing ribs and a wide latch area that produce an audible click to confirm secure mating, enhancing assembly reliability and ease of use. This reduces the risk of improper connections and ensures stable circuit integrity.

It is widely used in electronic components, power and connectors, electrical equipment manufacturing, and repair applications. Features a single row, straight orientation with shrouded design for secure mating retention.

Constructed with brass contacts plated in tin for reliable electrical conductivity. Supports a maximum current of 2A and voltage rating of 125V for standard PCB applications. Terminated by solder through hole mounting to ensure robust attachment on PCB.

Operating temperature range from -40°C to 105°C for diverse environmental conditions. Tail pin length of 3.3 mm for effective solder joint formation. Includes polarizing ribs and wide latch for audible and secure connection clicks.

Manufactured in the Republic of Korea adhering to Molex quality standards. Explore more Molex PCB Headers and connectors on EnvMart to find components suitable for a wide range of electronics manufacturing and repair needs.
