Alpha Wire Cable Gland Grey Chloroprene Rubber Polyamide M40 Thread Size 19-28 mm PMC40 SL080

Alpha Wire PMC40 SL080 cable gland is a high-quality wire management solution designed to provide secure strain relief and environmental protection for electrical and data cables. This gland incorporates a polyamide 6 body combined with a chloroprene rubber O-ring seal, finished in grey to suit industrial and commercial installations.

The M40 threaded cable gland accommodates cable diameters ranging between 19 mm and 28 mm, with a threading length of 10 mm and an outer thread diameter of 40 mm. Its robust rubber seal and locknut ensure tight clamping and minimize strain on cables, preventing wear and potential damage over time.

Rated to IP66 and IP68 standards, the gland provides excellent protection against dust ingress and can withstand submersion under fresh water beyond 1 metre for extended periods, making it suitable for demanding environmental conditions. It operates reliably in temperature ranges from -20°C to 150°C (with 100°C as permanent rating and 150°C for intermittent use), supporting heightened resistance requirements in various industrial settings.

Alpha Wire cable glands meet CSA and UL 514 electrical standards and UL 94 V-2 for flammability, ensuring compliance with international safety regulations. The flame retardant properties prevent flame spread, providing safer installations.

This cable gland is widely applied in telecommunications, control systems, instrumentation, and electrical power cabling where strain relief and protection are critical. It ensures system integrity against dust, dirt, sand, and moisture infiltration.

The product comes complete with a locknut to facilitate secure installation, enhancing cable retention and environmental sealing. Constructed from durable chloroprene rubber and polyamide materials for longevity. Suitable for cable diameters ranging from 19 mm minimum to 28 mm maximum.

Features an M40 thread size with 10 mm thread length and 40 mm thread diameter. Rated IP66 and IP68 for water and dust resistance to ensure secure protection. Includes locknut to ensure tight cable clamping and strain relief.

Operating temperature range from -20°C up to 150°C intermittent use. Compliant with CSA, UL 514, and UL 94V-2 flammability standards with V2 flame retardant rating. Ideal for telecommunications, control, instrumentation, data, and electrical power cable applications.

Designed to resist dirt, dust, water, and sand ingress, ensuring system reliability. Explore more Cable Glands and wire management products on EnvMart for your industrial and commercial electrical needs.
