Microchip 8-bit PIC Microcontroller PIC16F1509-I/SO 20 MHz 14kB FLASH 20-Pin SOIC
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Height | 2.05mm |
| Length | 12.8mm |
| Model | PIC16F1509-I/SO |
| Width | 7.5mm |
| Mount Type | Surface |
| Series | PIC16F |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Ram size | 512bit |
| Standards/Approvals | RoHS |
| Pin Count | 20 |
| Automotive Standard | ISO/TS 16949 |
| Maximum Supply Voltage | 5.5V |
| Maximum Power Dissipation Pd | 800mW |
| Minimum Supply Voltage | 2.3V |
| Device Core | PIC |
| Program Memory Size | 14kB |
| Maximum Clock Frequency | 20MHz |
| Number of Programmable I/Os | 18 |
| Analogue Comparators | 2 |
| Number of Timers | 3 |
| Instruction Set Architecture | RISC |
| ADCs | 12 x 10 Bit |
| Program Memory Type | FLASH |
| DACs | 1 x 5 Bit |
Key Features
- 8-bit PIC architecture providing up to 5 MIPS performance.
- 14kB of flash program memory and 512-bit RAM.
- 20 MHz maximum clock frequency with configurable oscillator having ±1% accuracy.
- Contains 18 programmable I/O pins and supports in-circuit serial programming and debugging.
- Features 12-channel 10-bit ADC, 5-bit DAC, and two analog comparators.
- Operating voltage range from 2.3V to 5.5V for flexible power management.
- Wide operating temperature range from -40°C to 85°C suitable for industrial applications.
- Compliant with RoHS and automotive standard ISO/TS 16949.
Product Description
Microchip PIC16F1509-I/SO is an 8-bit PIC microcontroller featuring the enhanced mid-range core architecture delivering up to 5 million instructions per second (MIPS) at a maximum clock speed of 20 MHz. This MCU provides 14kB of FLASH memory and 512 bits of RAM, equipped with a configurable internal oscillator with ±1% frequency accuracy, making it ideal for precise embedded applications.
Designed in a compact 20-pin SOIC surface mount package, it offers 18 configurable I/O pins, enabling versatile interfacing options in compact PCB layouts. The device supports in-circuit serial programming (ICSP) and debugging (ICD), enhancing development flexibility. It includes multiple timers consisting of two 8-bit timers and one 16-bit timer, along with four 10-bit PWM modules for motor control and signal generation.
The microcontroller features a 12-channel, 10-bit analog-to-digital converter (ADC), a 5-bit digital-to-analog converter (DAC), and two analog comparators, suitable for analog signal processing tasks. Communication peripherals include a Master Synchronous Serial Port (MSSP) supporting SPI and I2C protocols, as well as an Enhanced Universal Synchronous Asynchronous Receiver Transmitter (EUSART) for serial communication.
Operation is possible over a voltage range of 2.3V to 5.5V and an ambient temperature range from -40°C to 85°C, making it suitable for automotive and industrial environments complying with ISO/TS 16949 standards. The product meets RoHS compliance, supporting environmentally responsible applications.
8-bit PIC architecture with 16-level hardware stack. 14kB FLASH program memory and 512-bit RAM capacity. 18 programmable I/Os in 20-pin SOIC package. 20 MHz maximum CPU clock speed with ±1% oscillator accuracy. 12-channel 10-bit ADC and 5-bit DAC for mixed-signal applications.
Supports SPI, I2C, and EUSART communication interfaces. Wide operating voltage (2.3V to 5.5V) and temperature range (-40°C to 85°C). Compliant with RoHS and ISO/TS 16949 automotive standard. Compact dimensions of 12.8mm length, 7.5mm width, and 2.05mm height.
This microcontroller is suitable for industrial automation, automotive control systems, consumer electronics, and embedded system development. It balances performance, low power consumption via XLP technology, and comprehensive peripheral integration, enabling efficient application designs.
Explore EnvMart's extensive selection of Microcontrollers for your next embedded design project.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum clock frequency of this microcontroller is 20 MHz.
It features a program memory size of 14kB FLASH.
This microcontroller has 18 programmable I/O pins.
The operating voltage range is from 2.3V to 5.5V.
It operates within a temperature range of -40°C to 85°C, suitable for industrial applications.
It supports SPI, I2C, and EUSART communication interfaces.
This microcontroller is in a 20-pin SOIC package with dimensions of 12.8mm length, 7.5mm width, and 2.05mm height.
It has a RAM size of 512 bits.
It features a 12-channel 10-bit ADC and a 5-bit DAC.
It is compliant with the ISO/TS 16949 automotive standard.
The maximum power dissipation is 800 mW.
It is suitable for industrial automation, automotive control systems, consumer electronics, and embedded system development.
