Schneider Electric TeSys D 42V AC Coil 4-Pole 25A 2 NO/2 NC 690V AC/DC Contactor LC1D128D7
Specifications
| Country of Origin | Indonesia |
|---|---|
| Brand | Schneider Electric |
| Function | Resistive Load |
| Length | 85mm |
| Model | LC1D128D7 |
| Depth | 92mm |
| Width | 45mm |
| Mount Type | DIN Rail |
| Series | LC1D |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -40°C |
| Terminal type | Screw |
| Number of Poles | 4 |
| Standards/Approvals | EN 60947-4-1 |
| Contact Voltage | 690V ac/dc |
| Coil Voltage | 42V ac |
| Normal State Configuration | 2 NO/2 NC |
| Better World Claim | Designed for Disassembly |
| Contact Current | 25A |
| Number of Auxiliary Contacts | 2 |
| Auxiliary Contact Configuration | 1 NO/1 NC |
| Operational Current Ie | 25A |
| Control Circuit Voltage Uc | 42V ac |
| Contactor Application | Resistive Load |
| Pole and Throw Configuration | 4 |
| Screw connections | IP20 finger-safe terminals with both North American and International terminal markings |
| AC-1 | This applies to all AC devices with a power factor of at least 0.95. Example of use: resistive load, heating, distribution |
| AC-3 | This applies to squirrel cage motors where breaking occurs while the motor is running. Example of use: all squirrel cage motors, lifts, escalators, conveyors, bucket elevators, compressors, pumps, mixers, air conditioning units |
Key Features
- Operates with a coil voltage of 42V AC for efficient control circuits.
- 4-pole configuration with contact voltage capacity of 690V AC/DC.
- Rated contact current and operational current of 25A for high reliability.
- Includes 2 normally open (NO) and 2 normally closed (NC) auxiliary contacts.
- Mounts easily on DIN rail with screw terminal connections.
- Supports a wide operating temperature range from -40°C to 60°C.
- Complies with EN 60947-4-1 standard ensuring international quality and safety.
- Designed for resistive load applications and industrial control systems.
Product Description
Schneider Electric LC1D128D7 TeSys D Contactor is a robust industrial contactor designed to handle resistive loads and motor control tasks with high reliability. Featuring a coil voltage of 42V AC, this contactor ensures wide control voltage compatibility while maintaining low power consumption.
The contactor has a 4-pole configuration rated for contact voltages up to 690V AC/DC and a contact current capacity of 25A, suitable for various industrial and automation applications. It is equipped with 2 normally open and 2 normally closed auxiliary contacts, facilitating versatile control logic designs.
Constructed for quick and secure installation, the device mounts on standard DIN rails and uses screw terminal types with IP20 finger-safe protection, meeting both North American and international terminal marking standards. It operates reliably across a temperature range of -40°C up to 60°C.
Designed according to EN 60947-4-1 standards, the contactor guarantees compliance with international safety and performance norms. Its compact size (85mm length, 45mm width, 92mm depth) makes it suitable for panel mounts in control gear systems.
Typical industrial use cases include automation, motor starters, resistive load control, conveyor systems, pump and compressor management, and HVAC controls. This model's design also supports sustainable practices with features like Designed for Disassembly under Schneider Electric's Better World program.
Operates with a 42V AC coil voltage ensuring control circuit compatibility. 4 pole design rated for 25A contact current and 690V AC/DC contact voltage. Configuration includes 2 normally open and 2 normally closed auxiliary contacts.
Mounts easily on DIN rails and uses IP20 finger-safe screw terminals. Suitable for resistive loads and motor control applications in industrial settings. Wide operating temperature range: -40°C to 60°C for robustness in varied conditions.
Meets EN 60947-4-1 international electrical standards for contactors. Compact dimensions enable efficient panel space usage. Designed under Schneider Electric's Better World initiative for sustainability. Explore a wide range of Contactors and control gear products on EnvMart for your industrial automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The LC1D128D7 contactor operates with a coil voltage of 42V AC, ensuring compatibility with various control circuits.
This model has a rated contact current of 25A, making it suitable for high reliability in industrial applications.
The contactor is rated for a maximum contact voltage of 690V AC/DC, allowing it to handle a wide range of electrical loads.
It includes 2 normally open (NO) and 2 normally closed (NC) auxiliary contacts, providing versatile control options.
This contactor operates reliably within a temperature range of -40°C to 60°C, suitable for various environmental conditions.
The contactor complies with the EN 60947-4-1 standard, ensuring it meets international quality and safety requirements.
It mounts easily on DIN rails, utilizing screw terminal connections for secure installation.
The dimensions of this model are 85mm in length, 45mm in width, and 92mm in depth, allowing for efficient panel space usage.
This contactor is designed for resistive load applications, making it suitable for various industrial control tasks.
It features IP20 finger-safe screw terminals, which comply with both North American and international terminal marking standards.
Typical applications include motor starters, conveyor systems, pump management, and HVAC controls, among others.
It is designed under Schneider Electric's Better World initiative, which focuses on sustainability and features like Designed for Disassembly.
