Littelfuse Non-Resettable Fuse 500mA 125V Ceramic Body Time Delay 0452.500MRL

Littelfuse 0452.500MRL Non-Resettable Fuse is a 500mA, 125V surface mount fuse designed for circuit protection in electronic and electrical applications.

This fuse belongs to the Littelfuse 452 Series NANO2 surface mount fuses, providing enhanced inrush withstand characteristics that reduce nuisance opening due to transient currents. Its ceramic body ensures mechanical strength and heat resistance, suitable for demanding environments.

The fuse is time-delay type, ideal for protecting sensitive electronic components in devices such as alarm systems, audio/visual equipment, computer boards, portable telephones, power supplies, and medical apparatus. The gold-plated terminals improve electrical connectivity and reliability.

With a breaking capacity of 50A and compliance with CSA, RoHS, and UL 248-14 standards, this fuse offers robust protection meeting international safety norms.

The compact size with 2.69mm width and height and 6.1mm depth makes it a space-saving solution in PCB layouts. It operates reliably over a temperature range from -55°C to 125°C, accommodating various operating conditions.

This fuse is packaged on a reel, facilitating automated insertion into machinery and enhancing production efficiency in mass assembly. The fuse features a ceramic body construction for enhanced durability. It is a time-delay fuse designed to handle inrush currents without nuisance opening.

Rated for a current of 500mA and voltage of 125V. The fuse has gold-plated terminals for reliable connectivity. It offers a breaking capacity of 50A for effective circuit protection. Operates effectively within temperatures from -55°C to 125°C.

Compact dimensions with 2.69mm width and height, and 6.1mm depth. Complies with CSA, RoHS, and UL 248-14 standards ensuring safety and quality.

This Littelfuse Non-Resettable Fuse is widely used in electronics manufacturing, electrical equipment maintenance, and industrial control systems where reliable circuit interruption is critical. It is especially suitable for industrial, commercial, and laboratory equipment requiring precise current protection in surface mount circuits.
