Siemens Acti9 iC60L Miniature Circuit Breaker, 4-Pole, 16A, Type C, Thermal Magnetic, Screw Terminal, IP20 A9F94416

Schneider Electric A9F94416 Acti9 iC60L Miniature Circuit Breaker, 4-Pole, 16A, Type C, is a high-quality circuit protection device designed for industrial, commercial, and residential electrical systems. This breaker combines thermal magnetic tripping mechanism with Type C characteristics that enable it to trip instantly at five to ten times the rated current, ensuring effective protection against short circuits and overloads.

Rated for AC voltages from 100V to 440V and DC voltage up to 250 V DC, this MCB offers flexibility across various electrical configurations. The device has a breaking capacity of 10 kA, making it suitable for handling high fault currents. Its compact dimensions (85mm height, 72mm width, 78.5mm depth) and DIN rail mount design facilitate easy integration into electrical panels.

The breaker features screw terminal connections providing reliable and robust contacts with double tightening torque. IP20 insulation class protects users from accidental contact with live parts while maintaining durability in challenging environments. The toggle switch reset actuator offers straightforward manual operation.

Compliant with internationally recognized standards such as IEC/EN 60898-1 and IEC/EN 60947-2, this MCB assures top-class safety and performance. It is engineered to withstand polluted surroundings and high inductive loads, common in industrial buildings.

Innovative visual features include VisiSafe, which ensures that downstream circuits are safe regardless of overvoltage conditions by indicating the secure contact position with a green strip. The VisiTrip red window signals fault occurrences, allowing for rapid identification, troubleshooting, and resetting, thus reducing downtime and maintenance complexity.

Manufactured in France, this Miniature Circuit Breaker is built with class-2 insulation, guaranteeing continuous protection for operators and unqualified personnel alike. This 4-pole MCB offers protection against short circuits and overloads in industrial and commercial settings.

Thermal magnetic tripping with Type C curve ensures reliable fault interruption within 5 to 10 times rated current. Suitable for AC voltages between 100V and 440V and DC voltage up to 250 V DC. Enabled with screw terminals and mounted on DIN rails for secure installation and ease of maintenance.

IP20 rated insulation and class-2 insulation ensure operator safety. Visual contact position indicator (VisiSafe) and fault trip indicator (VisiTrip) simplify diagnostics. Standards compliance with IEC/EN 60898-1, IEC/EN 60947-2, REACH, and RoHS.

Compact dimensions allow installation flexibility in standard electrical panels. Ideal for high inductive load environments and polluted atmospheres. Explore EnvMart's range of advanced circuit protection devices to ensure industrial and commercial electrical safety with Schneider Electric’s trusted solutions.
