Siemens Acti9 iC60L Miniature Circuit Breaker 4-Pole 40A Type C Thermal Magnetic 10kA Breaking Capacity A9F94440

Schneider Electric A9F94440 Acti9 iC60L Miniature Circuit Breaker is a 4-pole device rated at 40A with a Type C thermal magnetic trip characteristic. It provides reliable protection against overloads and short circuits, ensuring electrical safety in industrial, commercial, and residential applications. This breaker offers a breaking capacity of 10kA, making it suitable for networks with high current surges and inductive loads.

Designed for DIN Rail mounting, the breaker is compact with dimensions of 85mm height, 72mm width, and 78.5mm depth. It features screw terminal connections and insulated terminals rated IP20, offering enhanced operator safety. The device supports a wide range of rated voltages including AC voltage ranges from 100V up to 440V and a DC voltage rating of 250V.

Acti9 iC60L series circuit breakers comply fully with EN/IEC 60898-1 and EN/IEC 60947-2 standards, guaranteeing installation safety and conformity in demanding environments. The thermal magnetic tripping mechanism promptly reacts to overload conditions, while the Type C curve allows tripping at 5 to 10 times the rated current, protecting circuits handling high inductive loads effectively.

Additional safety features include VisiSafe to ensure downstream circuits remain safe even under overvoltage conditions, and a VisiTrip red fault indicator window for fast fault detection and quicker troubleshooting. The toggle switch reset actuator provides user-friendly manual operation.

This miniature circuit breaker is ideal for use in industrial control panels, manufacturing facilities, commercial buildings, and electrical distribution in various sectors that require effective and safe circuit protection.

Suitable for DIN Rail mounting in industrial and commercial electrical installations. Type C trip curve triggers at 5 to 10 times the rated current, ideal for high inductive loads. Rated AC voltages from 100V to 440V and DC voltage rated at 250V dc.

Equipped with screw terminals and IP20 rated insulated terminals for safety. Compact dimensions: 85mm height, 72mm width, and 78.5mm depth. Thermal magnetic tripping ensures protection against overload and short circuits.

Compliance with EN/IEC 60898-1 and EN/IEC 60947-2 standards. VisiSafe and VisiTrip indicators allow for easy fault diagnosis and safety confirmation.
