Schneider Electric 8A Thermal Magnetic ICT Series Motor Protection Circuit Breaker 690V A9E21180

Schneider Electric A9E21180 Motor Protection Circuit Breaker is a robust thermal magnetic circuit breaker designed for protecting electric motors against overload and phase asymmetry. With a current rating of 8A and a supply voltage of 690V, it operates effectively within a temperature range of -5°C to 55°C. This three-pole breaker is part of the ICT series from Schneider Electric, renowned for their reliability and precise motor protection capabilities.

Its compact size (88.1mm length × 36mm width × 67mm depth) and an IP20 rating provide a practical, space-saving solution suitable for industrial electrical panels and motor control centers. The device features thermal and magnetic sensing methods for superior detection of overload and short circuit conditions.

The breaker includes user-friendly features such as a DIN rail clip and clearly labelled terminals for ease of assembly and maintenance. It complies with international safety and quality standards including DNV GL, ATEX, BV, CCC, CSA, EAC, EN/IEC 60947-2, EN/IEC 60947-4-1, IECEE CB, LROS, REACH/RoHS, RINA, and UL, making it suitable for demanding industrial environments.

Applications include protection of electric motors in HVAC equipment, hoists and cranes, and compressors. It ensures reliable phase control and safety monitoring of three-phase circuits, helping prevent costly motor damage and downtime.

Offers thermal magnetic sensing for precise motor protection and overload detection. Rated for 3 poles and operates within -5°C to 55°C temperature range. Compact dimensions with 88.1mm length, 36mm width, and 67mm depth ensure easy DIN rail mounting.

Equipped with IP20 rating for basic protection against solid objects. Complies with multiple international standards including IEC 60947-2 and UL for safe industrial use. Supports phase asymmetry detection and motor protection applications including HVAC equipment, hoists, and cranes.

Designed with DIN rail clip and labelled terminals for simplified installation. Manufactured in Italy ensuring high-quality engineering and durability.

Choose Schneider Electric ICT series for reliable, compliant motor protection solutions. Browse related Motor Protection Circuit Breaker products and other Schneider Electric offerings on EnvMart.
