Block PCB Transformer 24 V ac 1 Output Pin Mount 0.5VA Power VB 0,5/1/24

Block VB 0,5/1/24 PCB Transformer is a precision electronic component designed for mounting directly onto printed circuit boards. It offers a secondary voltage of 24 V ac at 0.5VA power capacity, making it ideal for low power applications in industrial and commercial electronics.

The transformer features a single output winding and a primary input voltage of 230 V ac compatible with standard AC mains. Designed with a compact footprint of 22 mm length, 22.7 mm width, and 19 mm depth, the component supports pin mounting to facilitate secure PCB installation.

Constructed from vacuum epoxy resin with UL94-V0 rating and glass fiber reinforced polyamide bobbins, this transformer provides robust electrical insulation and mechanical strength. The unit is inherently short circuit proof and ensures a high isolation voltage of 5000 V, enhancing safety in electrical systems.

Operating temperatures can reach up to 70°C, ensuring stable performance under demanding conditions. The transformer complies with stringent international and European safety standards including VDE 0570 Part 2-6, IEC 61558-2-1, ENEC 10, and C-UL-US approvals, confirming its reliability and safety for industrial use.

Compact pin mount design allows easy PCB integration. Primary voltage of 230 V ac suitable for standard mains supply. Single output winding ensures stable transformer operation. Isolation voltage rated at 5000 V for safety and reliability.

High operating temperature range up to 70°C allows use in varied environments. Conforms to multiple safety standards including VDE 0570 and IEC 61558. Constructed with vacuum epoxy resin and reinforced polyamide bobbins for durability.

Low temperature rise and high efficiency contribute to longer life. Weight of 40 grams supports lightweight electronic designs. Frequency range supports 50 Hz to 60 Hz mains supply.

This PCB transformer from Block is suitable for electronic, industrial, manufacturing, and laboratory applications where reliable AC voltage transformation is required on circuit boards. Its compliance with international standards makes it a dependable choice for integration into power supply and connector systems.
