TE Connectivity Power Relay PCB Mount 5V DC Coil Voltage 6A Switching Current SPST Contact Configuration 9-1415067-1

TE Connectivity 9-1415067-1 power relay is a high-performance component intended for printed circuit board mounting. It operates with a 5V DC coil voltage and a switching current of up to 6 amperes, making it suitable for a variety of electrical and industrial applications requiring reliable switching.

The relay features a single pole single throw (SPST) contact configuration within the SNR series, characterized by a slim design just 5mm thick, facilitating installation in compact and high-density PCB assemblies. The coil has a sensitivity of 170 milliwatts and a resistance of 147 ohms, optimized for low power consumption.

Engineered to function in a broad temperature range from -40 to +85 degrees Celsius, this relay performs reliably even under demanding environmental conditions. It offers an isolation voltage of 4000 Vac between the coil and contact, ensuring enhanced electrical safety in circuit designs.

Its contact material consisting of silver alloy guarantees excellent conductivity and durability over prolonged use. The solder-type terminals provide robust mechanical and electrical connections for stable installation. With rated values of 400V AC switching voltage and switching power up to 1.5 kVA, it caters well to control, automation, and signal switching tasks.

Dimensions measuring 28mm in length, 15mm in height, and 5mm in width make it compatible with standard PCB layouts. The product meets stringent international certifications including IEC, REACH, RoHS, VDE, and UL, ensuring compliance with industry quality and safety benchmarks.

This power relay is ideal for use across industrial automation, electrical control systems, manufacturing equipment, and other commercial electronics requiring dependable switching functionality. Its compactness and performance characteristics enable effective integration into various electrical assemblies and circuit designs.

This relay features a single pole single throw (SPST) contact configuration. The compact SNR series relay has a slim 5mm thickness for high-density PCB designs. It offers high coil sensitivity at 170mW and coil resistance of 147 ohms.

Operating temperature ranges from -40 to +85 degrees Celsius, suitable for harsh conditions. Isolation voltage of 4000 Vac ensures electrical safety between coil and contacts. The relay contacts use silver alloy material for reliable switching performance.

Terminals are designed for solder mounting providing secure electrical connections. Rated switching AC voltage is 400V AC with switching power of 1.5 kVA. Dimensions are 28mm length, 15mm height, and 5mm width for PCB compatibility.

The relay complies with IEC, REACH, RoHS, VDE, and UL standards for quality and safety. Explore more power relay options from TE Connectivity in the Electronics & Electricals category at EnvMart.
