Telemecanique Sensors Retroreflective Photoelectric Sensor Barrel Style 24V DC 100mA PNP Output IP65 IP67 XUB1BPANM12

Telemecanique Sensors XUB1BPANM12 is a high-performance retroreflective photoelectric sensor designed for reliable detection of metal objects in automated industrial environments. Featuring a barrel style housing constructed from nickel plated brass, this sensor combines durability with compact form factor, making it suitable for installation where space is constrained.

Operating at 24 V DC, the sensor uses an infrared light source with a retroreflective detection type, enabling precise sensing up to 4 meters distance. It delivers a solid-state PNP output, rated for a maximum current of 100 mA and offers a rapid response time of 1 millisecond, which is critical in high-speed automation processes.

The sensor is rated with ingress protection IP65 and IP67, providing robust resistance against dust and water ingress, and is compliant with safety and quality standards including CE, UL, and CSA. The operating temperature range spans from -25°C to 55°C, ensuring stable performance under varying environmental conditions.

Due to its nickel plated brass housing, the XUB1BPANM12 sensor is durable and resistant to mechanical wear. Its lightweight design, weighing only 0.05 kg, allows for easy mounting and reduced mechanical stress on supporting structures.

This Photoelectric Sensor is ideal for various industrial automation applications including material handling, manufacturing, conveyor systems, and process control. It ensures accurate detection of metal materials, enhancing process efficiency and safety.

Barrel style sensor housing made from nickel plated brass ensures durability. Detection range up to 4 meters with infrared light source. Wide operating temperature from -25°C to 55°C. Ingress protection rated IP65 and IP67 for harsh environments.

Maximum current rating of 100 mA with a fast 1 ms response time. Compliant with CE, UL, and CSA standards for quality and safety. Compact size with diameter 18 mm and length 62 mm, weighing only 0.05 kg. Reliable use in industrial automation and control applications.
