HARWIN 2 mm Pitch Male Pin Backplane Connector, Straight Male, 16 Column, 4 Row, 120 Way M22-6023042

HARWIN M22-6023042 is a 2 mm pitch male pin backplane connector featuring 120 contacts arranged in 16 columns and 4 rows, specifically designed for embedded PC applications and PC/104 Plus connectors compatible stacking boards. The connector adopts a straight male orientation, ensuring precise and reliable mating in backplane rack connectors.

The housing is constructed from robust nylon material, ensuring durability and mechanical strength in harsh environments. Brass contacts with gold plating provide excellent electrical conductivity and corrosion resistance necessary for demanding industrial applications.

It supports a current rating of 1 ampere per contact with operation stability between -55°C and 105°C, making it suitable for a wide range of temperature conditions. This connector utilizes a through-hole mount type and a solder termination method, providing secure assembly in electronic manufacturing.

The M22-6023042 connector Series supports the PC104 industry standard, widely used for stacking multiple boards with a common bus, especially for embedded computing systems requiring compact and reliable interconnections.

The connector features 120 brass contacts with gold plating for enhanced conductivity and durability. Its nylon housing material contributes to robustness and long service life. The design supports a continuous current load of 1 ampere per pin.

Operating temperature range of -55°C to 105°C ensures adaptability to extreme environments. Through-hole mounting and solder termination guarantee stable and strong mechanical and electrical connections. It complies with industrial standards for embedded PC backplane connectors.

Manufactured in Taiwan, ensuring quality and consistency.

This connector is ideal for electronics manufacturing, industrial embedded systems, telecommunications, and electronic instrumentation. It facilitates efficient stacking and interconnection of boards in compact spaces while maintaining electrical reliability.
