RS PRO D-Sub Connector 15 Way Right Angle 2.77 mm Pitch Through Hole Female with 4 to 40 UNC Screw Lock A-DF 15 A/KG-T1
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 250V |
| Brand | RS PRO |
| Orientation | Right Angle |
| Current | 3A |
| Model | A-DF 15 A/KG-T1 |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Brass |
| Series | A-DF |
| Mounting Hardware | 4 to 40 UNC Screw Lock |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Pitch | 2.77mm |
| Contact Plating | Nickel, Gold |
| Number of Contacts | 15 |
| Contact Gender | Female |
| Connector Gender | Female |
| Connector Type D | D-Sub |
| D-Sub Shell Size | DF-15 |
Key Features
- Supports a current rating of 3 Amperes for reliable power connection.
- Features a 4 to 40 UNC screw lock for secure mounting and connection stability.
- Constructed with brass contacts plated in nickel and gold to ensure corrosion resistance.
- Housing made from durable polybutylene terephthalate to withstand operating temperatures from -40°C to 105°C.
- Designed for through hole PCB mounting with a DF-15 shell size suitable for industrial electronic applications.
- Termination accomplished by soldering for permanent and stable electrical connections.
- Right angle orientation optimizes PCB layout flexibility.
Product Description
ASSMANN WSW A-DF 15 A/KG-T1 is a 15 way right angle D-Sub connector featuring a 2.77 mm pitch and female connector gender, ideal for secure electronic component interfacing. It operates at a voltage of 250 volts and supports current up to 3 amperes, suitable for a variety of industrial and electronic applications.
The connector is designed for through hole mounting on PCBs, providing reliable mechanical and electrical connections enhanced by a 4 to 40 UNC screw lock mechanism. The shell size type is DF-15, matching standard D-Sub connector formats.
Contacts are made from brass and plated with nickel and gold to resist corrosion and ensure long-lasting conductivity. The housing material is polybutylene terephthalate, giving it robustness for harsh environmental conditions with an operating temperature range from -40°C to 105°C.
This solder termination type connector offers a right angle orientation, which allows for compact and efficient circuit board design layouts. It is a component commonly used in electronics manufacturing, telecommunications, industrial automation, and instrumentation sectors.
Manufactured in China, this connector meets standard quality requirements and ensures compatibility with Euro-standard D-Sub Connector systems. Supports a current rating of 3 Amperes for reliable power connection. Features a 4 to 40 UNC screw lock for secure mounting and connection stability.
Constructed with brass contacts plated in nickel and gold to ensure corrosion resistance. Housing made from durable polybutylene terephthalate to withstand operating temperatures from -40°C to 105°C. Designed for through hole PCB mounting with a DF-15 shell size suitable for industrial electronic applications.
Termination accomplished by soldering for permanent and stable electrical connections. Right angle orientation optimizes PCB layout flexibility. Explore EnvMart's extensive range of electronic connectors for varied industrial and manufacturing requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a current rating of 3 Amperes, ensuring reliable power connection.
This model operates at a voltage of 250 volts, suitable for various electronic applications.
The contacts are made from brass and plated with nickel and gold for corrosion resistance, while the housing is constructed from polybutylene terephthalate.
It features a pitch size of 2.77 mm, which is standard for this type of connector.
This connector is designed for through hole mounting on printed circuit boards (PCBs).
It utilizes solder termination for permanent and stable electrical connections.
This model features a right angle orientation, which optimizes PCB layout flexibility.
It has 15 contacts, designed for various electronic interfacing applications.
It includes a 4 to 40 UNC screw lock for secure mounting and connection stability.
It is manufactured in China, adhering to standard quality requirements.
