TRACOPOWER Switching Regulator Through Hole Mount 5V DC Output Voltage 1A Output Current 5W Power TSR 1-2450

Free Delivery in India | Lowest Global Shipping Charges

TRACOPOWER Switching Regulator Through Hole Mount 5V DC Output Voltage 1A Output Current 5W Power TSR 1-2450

Name: TRACOPOWER Switching Regulator Through Hole Mount 5V DC Output Voltage 1A Output Current 5W Power TSR 1-2450
Brand: TRACOPOWER
SKU: 204447
Price: 8.91 USD
Availability: InStock



Category Switching Regulators Brand TRACOPOWER Condition New

Specifications

Country of Origin	Taiwan
Brand	TRACOPOWER
Power	5W
Efficiency	93%
Length	11.7mm
Model	TSR 1-2450
Depth	10.2mm
Gross Weight	1.9g
Width	10.2mm
Mount Type	Through Hole
Series	TSR 1
Output Current	1A
Maximum Operating Temperature	85°C
Package Type	SIP-3
Load Regulation	±0.4 %
Minimum Operating Temperature	-40°C
MTBF	5350000h
Number of outputs	1
Ripple and Noise	50mV Pk-Pk
Maximum Input Voltage	36V dc
Line Regulation	±0.2 %
Standards/Approvals	CE
Minimum Input Voltage	6.5V
Output Voltage 1	5V dc
TRACOPOWER Switching Regulator, Through Hole, 1 A Output CurrentBrand	TRACOPOWER

Key Features

Features a SIP-3 package type suitable for PCB through-hole mounting.
Provides high efficiency of 93% to minimize power loss and heat generation.
Ensures output voltage stability with ±0.2% line regulation and ±0.4% load regulation.
Operates within a temperature range of -40°C to 85°C for reliable performance.
Maximum ripple and noise voltage is kept low at 50mV peak-to-peak to ensure signal integrity.
Integrated short-circuit protection with automatic restart improves system robustness.
Fast response time of 250 microseconds to dynamic load changes.
Certified with CE standards and has an excellent MTBF of over 5 million hours.

Product Description

TRACOPOWER TSR 1-2450 is a high-performance switching regulator designed for through-hole mounting on PCBs. It provides a regulated 5V DC output voltage at 1A current, delivering 5W of power with exceptional efficiency of 93%. Its SIP-3 package offers compact dimensions (11.7 x 10.2 x 10.2 mm), making it ideal for space-constrained applications.

This regulator supports a wide input voltage range from 6.5V to 36V DC and maintains stable output with minimal ripple and noise, measured at 50mV peak-to-peak. With line regulation of ±0.2% and load regulation of ±0.4%, it ensures precise voltage delivery under variable conditions.

The device operates reliably in harsh environments with operating temperatures spanning from -40°C to 85°C. Its built-in short-circuit protection automatically restarts the regulator after fault conditions, reducing downtime and enhancing system reliability. The fast response time of 250 microseconds enables swift load change adaptations.

This switching regulator is suitable for diverse industrial and electronic applications, including automotive systems, domestic appliances, and robotic controls. Its CE certification guarantees compliance with safety standards, and an impressive MTBF rating of 5,350,000 hours highlights its longevity.

Through-hole mounting SIP-3 package for easy PCB integration. High efficiency reduces energy waste and heat generation. Wide input voltage range supports flexible power sources. Stable 5V DC output with precise regulation metrics.

Robust short-circuit protection with auto-restart feature. Fast transient response for dynamic load handling. Compact and lightweight design at 1.9 grams. Applicable for automotive, domestic, and robotics systems. CE certified for safety and quality assurance.

Explore more TRACOPOWER solutions and industrial-grade voltage converters on EnvMart for efficient and reliable power management components.

Explore more products in our Switching Regulators category.
