Sensirion Air Quality Sensor Development Tool Evaluation Kit with SVM40 SGP40 and SHT40 Sensors SEK-SVM4x
Specifications
| Country of Origin | India |
|---|---|
| Brand | Sensirion |
| Model | SEK-SVM4x |
| Sensor Technology | Air Quality Sensor |
| Interfaces | USB-UART cable, jumper wire cable set |
| For Use With | SGP40/41 |
| Standards/Approvals | RoHS |
| Kit Classification | Evaluation Kit |
| Featured Device | SVM40 sensor module equipped with SGP40, SHT40 |
| Kit Name | SEK-SVM4x Evaluation Kit for SGP40/41 |
Key Features
- The kit features the SVM40 development board with integrated SGP40 and SHT40 sensors.
- Provides VOC, temperature, and humidity measurements with high accuracy.
- Equipped with USB-UART and jumper wire cables for easy connection to embedded platforms.
- Interfaces include I²C and UART with digital output signals.
- Device-to-device variations are specified for VOC and NOx sensors ensuring consistent performance.
- Recommended operating conditions range from 0 to 90 % relative humidity and -10 to +50 °C.
- Compact sensor module dimensions of 39 mm x 15 mm x 5.5 mm and lightweight at 4.6 grams.
- Suitable for embedded applications including Arduino and Raspberry Pi platforms.
Product Description
The Sensirion SEK-SVM4x Evaluation Kit is a comprehensive air quality sensor development tool that integrates a SVM40 sensor module equipped with the SGP40 VOC sensor and SHT40 humidity and temperature sensor. It offers precise air quality measurements with a compact design operating on a supply voltage from 3.0 to 5.5 V. This new kit is designed to facilitate air quality sensing development with I²C and UART digital output signals for signal processing.
The included SVM40 development board features these sensors with an on-board microcontroller for enhanced signal processing capabilities. The kit comes with a USB-UART cable and jumper wires, enabling straightforward connection to embedded platforms such as Arduino and Raspberry Pi. This makes it ideal for prototyping, development, and evaluation of air quality sensors.
Device-to-device variations are controlled for VOC and NOx measurements, with VOC variations within ±15 index points or percentage and NOx variations within ±50 index points or percentage, whichever is larger. The sensor operates reliably over a recommended humidity range of 0 to 90 %RH and temperature range of -10 to +50 °C. Min/max operating conditions extend slightly to avoid condensation.
The sensor module is compact with dimensions 39.00 mm by 15.00 mm by 5.5 mm and a lightweight 4.6 grams, making it suitable for embedded applications requiring precise environmental data. It is designed for industrial, laboratory, and embedded computing environments.
The kit includes the SVM40 development board with integrated SGP40 VOC and SHT40 sensors. On-board microcontroller offers advanced signal processing capabilities. Interfaces support I²C and UART digital outputs. Equipped with USB-UART cable and jumper wires for easy connectivity.
Device-to-device sensor variation specifications ensure consistent measurement accuracy. Operating conditions suitable for varied environmental testing scenarios. Compact size and lightweight construction aid in easy integration.
Ideal for embedded platform development and prototyping.
It is an essential tool for embedded developers, researchers, and labs focusing on air quality sensor technologies. Explore the wide category of Sensor Development Tools at EnvMart for compatible accessories and complementary products.
