TDK Horizontal Coil Former for use with E 32/16/9 Core B66230A1114T001

Free Delivery in India | Lowest Global Shipping Charges

TDK Horizontal Coil Former for use with E 32/16/9 Core B66230A1114T001



Category Transformer Accessories Brand TDK Condition New

Specifications

Country of Origin	India
Brand	TDK
Material	Fibreglass Reinforced PolyTerephthalate
Length	37.5mm
Model	B66230A1114T001
Depth	25.4mm
Width	35mm
Maximum Operating Temperature	155°C
Accessory Type	Horizontal Coil Former
For Use With	E 32/16/9 Core
Standards/Approvals	RoHS
Number of Pins	14

Key Features

Made from fibreglass reinforced polyterephthalate material ensuring durability.
Rated maximum operating temperature of 155°C for high thermal performance.
Complies with RoHS standards ensuring environmental compliance.
Features 14 pins to accommodate specific coil configurations.
Compatible specifically with EPCOS E32/16/9 coil formers meeting IEC60085 insulation class UL 94 V-0.
Suitable for use in transformer assembly and repair applications.
Ensures solderability adhering to IEC 60068-2-58 for robust manufacturing processes.

Product Description

TDK B66230A1114T001 Horizontal Coil Former is a high-quality transformer accessory designed to support and shape coils for E 32/16/9 core transformers. Manufactured from fibreglass reinforced polyterephthalate material, this coil former delivers excellent mechanical strength and thermal stability with a maximum operating temperature of 155°C. It meets strict RoHS compliance standards, indicating its suitability for environmentally conscious applications.

The component measures 37.5mm in length, 35mm in width, and 25.4mm in depth, providing precise dimensions for fitting within transformer assemblies. Equipped with 14 pins, it facilitates secure coil mounting compatible with EPCOS E32/16/9 coil formers conforming to IEC60085 insulation class UL 94 V-0, ensuring high electrical insulation and fire resistance.

This coil former supports soldering processes compliant with IEC 60068-2-58 standards, enhancing the manufacturing reliability and longevity of transformer products. It is primarily applied in electronic component assemblies, power supplies, industrial transformers, and electrical distribution systems requiring robust coil insulation and structural support.

Made from fibreglass reinforced polyterephthalate for enhanced durability. Maximum operating temperature rated at 155°C for high-temperature environments. RoHS compliant ensuring eco-friendly manufacturing standards. Exact dimensions (LxWxD): 37.5mm x 35mm x 25.4mm for compatibility with E 32/16/9 cores.

Features 14 pins designed for secure coil mounting. Conforms to IEC60085 UL 94 V-0 insulation classification. Solderability compliant with IEC 60068-2-58 for manufacturing excellence.

This TDK coil former is an essential component within transformer manufacturing, electrical maintenance, and electronic equipment assembly involving coils with specified E32/16/9 cores. Its precise engineering and compliance with international standards make it ideal for industrial, laboratory, and commercial transformer coil assembly tasks.

Explore more TDK Transformer Accessories and related components to optimize your transformer build and repair processes.
