TDK Coil Former for use with PM 62/49 Core Fibreglass Reinforced PolyTerephthalate 155°C B65685A1000T001

TDK B65685A1000T001 coil former is a high-quality transformer accessory engineered for use with PM 62/49 cores. Manufactured from fibreglass reinforced polyterephthalate, this component withstands a maximum operating temperature of 155°C, ensuring excellent thermal stability in industrial and electronics applications.

The coil former measures 75.5 mm in length, 48.5 mm in width, and 53.7 mm in depth, providing a precise fit for PM ferrite cores commonly utilized in power repeaters, communications technology, and high-energy timed power supply devices. The design incorporates a holder clip and baseplate complete with nuts and washers to facilitate secure mounting on chassis or printed circuit boards (PCBs).

Installation instructions specify that the coil must be assembled with the soldered connections uppermost to maintain optimal electrical performance. The product is RoHS compliant, demonstrating conformity with environmental standards restricting hazardous substances.

This coil former supports various industrial use cases including transformer manufacturing and assembly, power supply unit construction, and applications requiring consistent electromagnetic component positioning on PCBs or chassis. Its robust material composition and dimensional accuracy contribute to reliable device operation under thermal stress.

TDK's engineering expertise ensures this coil former integrates seamlessly with PM 50-114 ferrite cores and similar EPCOS products, making it a dependable part in the transformer accessories category.

Constructed from fibreglass reinforced polyterephthalate for durability. Maximum operating temperature rating of 155°C suitable for demanding environments. Dimensions optimized with a length of 75.5 mm, width of 48.5 mm, and depth of 53.7 mm.

Compatible specifically with PM 62/49 ferrite cores used in power supplies and industrial electronics. Designed with holder clip and baseplate including nuts and washers for secure chassis or PCB assembly. Installation requires soldered connections to be oriented uppermost for reliable electrical contact.

RoHS compliant, ensuring adherence to hazardous substance regulations. Ideal accessory for transformer manufacturing, power repeaters, and high-energy timed power supply devices. Explore more products in Transformer Accessories at EnvMart for high-performance industrial and electronic components.
