Schneider Electric Motor Protection Circuit Breaker TeSyS GV, 14A Thermal Magnetic, 9A-14A Setting, 690V AC, 3 GV2RT16
Specifications
| Country of Origin | France |
|---|---|
| Brand | Schneider Electric |
| Model | GV2RT16 |
| IP Rating | IP20 |
| Overall Length | 89mm |
| Current Rating | 14, 9A |
| Series | TeSyS GV |
| Overall Width | 44.5mm |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -20°C |
| Sensing type | Thermal Magnetic |
| Supply Voltage | 690V ac |
| Number of Poles | 3 |
| Overall Depth | 78.5mm |
| Better World Claim | Designed for Disassembly |
| Motor Protection Component | Circuit Breaker |
| Motor Protection System | Motor Protection Circuit Breaker |
Key Features
- Equipped with thermal-magnetic protection adjustable between 9A and 14A settings.
- Designed for 3-pole motor circuits with compact dimensions of 89 x 44.5 x 78.5 mm.
- Screw clamp terminals ensure secure wiring and easy installation.
- Offers high breaking capacity of 15 kA at 400V, supporting motors up to 5.5 kW at 400V.
- Certified to multiple international standards including IEC, UL, CSA, and ATEX for diverse industrial applications.
- Provides robust mechanical service life of 100,000 operation cycles.
- Rated IP20 protection ensures safe handling against fingers and objects larger than 12mm.
- Suitable for use in power plants, industrial turbines, compressors, and generators.
Product Description
Schneider Electric GV2RT16 motor protection circuit breaker is a 3-pole thermal-magnetic device designed for motor protection applications requiring 14A current rating and 690V AC supply voltage. It features an adjustable thermal protection setting from 9A to 14A and a high magnetic tripping level at 20 times the nominal current. This circuit breaker supports motors with power up to 5.5 kW at 400V, making it suitable for a variety of industrial uses.
With compact dimensions of 89 mm height, 44.5 mm width, and 78.5 mm depth, the GV2RT16 fits well into tight control panel spaces. Screw clamp terminals deliver safe and reliable wiring connections. The product operates efficiently across a temperature range from -20°C to +60°C, enabling deployment in harsh environments.
This Motor Protection Circuit Breaker complies with multiple international standards including IEC 60947-4-1, IEC 60947-2, UL, CSA, ATEX, and others, ensuring it meets rigorous safety and performance requirements. Its IP20 rating provides protection against accidental contact and foreign object ingress.
Applications include protection of motors in power plants, industrial turbines, compressors, and generators. The device’s mechanical durability supports up to 100,000 operational cycles, guaranteeing long-lasting service in demanding industrial workflows.
Thermal-magnetic motor protection with adjustable current settings. High breaking capacity ideal for high starting current motors. Compact size reduces control panel footprint. Screw clamp terminal connections for secure wiring.
Wide operating temperature range suitable for harsh conditions. Compliance with major international safety standards. IP20 rating for safe handling. Robust mechanical service life ensuring reliability. Designed for disassembly enhancing sustainability.
Green Premium compliant for energy-efficient operations.
Choose Schneider Electric GV2RT16 for dependable motor protection in industrial, power generation, manufacturing, and HVAC applications. Explore similar products and detailed technical documentation on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an adjustable thermal protection setting ranging from 9A to 14A.
It is designed to operate at a maximum supply voltage of 690V AC.
The GV2RT16 offers a high breaking capacity of 15 kA at 400V.
The overall dimensions are 89 mm in height, 44.5 mm in width, and 78.5 mm in depth.
It features screw clamp terminals, which ensure secure wiring connections and easy installation.
This unit operates efficiently within a temperature range from -20°C to +60°C.
This circuit breaker is a 3-pole device, suitable for 3-pole motor circuits.
It complies with multiple international standards including IEC 60947-4-1, IEC 60947-2, UL, CSA, and ATEX.
It has a robust mechanical service life rated for 100,000 operational cycles.
It is suitable for protecting motors in applications such as power plants, industrial turbines, compressors, and generators.
The GV2RT16 has an IP20 rating, providing protection against accidental contact and foreign object ingress larger than 12mm.
It utilizes thermal magnetic sensing for motor protection.
