Siretta Stubby WiFi Antenna with SMA RP Connector, Dual Band WiFi, External Stubby Antenna TANGO25A/0.1M/SMAM/S/RP/29
Specifications
| Country of Origin | Taiwan |
|---|---|
| Brand | Siretta |
| Operating Temperature | -30 to +60˚C |
| Model | TANGO25A/0.1M/SMAM/S/RP/29 |
| Connector Type | SMA RP |
| Gross Weight | 13 g +/- 2 g |
| Series | Tango 25A |
| Gain | 2.4dB |
| Protection | IP65 |
| Impedance | 50 Ω |
| Maximum Frequency | 5GHz |
| Connector Gender | Male |
| Minimum Frequency | 2.4GHz |
| Internal/External | External |
| RF Protocols | WiFi (Dual Band) |
| Antenna Physical Form | Stubby |
| Antenna Mount Type | Through Hole/Bolted |
| Directivity | Omni-Directional |
| Polarisation | Vertical |
| WiFi/WLAN/Bluetooth/ZigBee | 2.4 GHz to 2.5 GHz |
| Radiation | Omnidirectional |
| VSWR | 2 max |
| Dual band WiFi | 5.1 GHz to 5.8 GHz |
| 22 mm (diameter), height | 22 mm (excluding screw thread) |
| Through hole mount | 8 mm long screw thread |
Key Features
- The antenna supports WiFi (Dual Band) protocols for 2.4 GHz and 5 GHz bands.
- Designed in a compact stubby form factor measuring 22 mm diameter and height.
- Features a through hole/bolted external mounting with an 8 mm long screw thread.
- Offers a gain of 2.4 dBi and omnidirectional radiation for reliable signal transmission and reception.
- Constructed with IP65 protection, making it resistant to dust and water for outdoor use.
- Operates efficiently between -30 to +60 degrees Celsius temperature range.
- Includes 100 mm RG174 coaxial cable terminated with a reverse polarity SMA male connector.
- Impedance is rated at 50 ohms with a maximum VSWR of 2 for effective signal matching.
Product Description
Siretta TANGO25A/0.1M/SMAM/S/RP/29 is a high-quality stubby WiFi antenna designed for dual band WiFi applications operating at 2.4 GHz and 5 GHz frequency bands. This external antenna features a compact stubby physical form measuring only 22 mm in diameter and height, suitable for devices requiring space-efficient antenna solutions. It uses a through hole/bolted mount with an 8 mm screw thread for secure and stable installation.
The antenna delivers a gain of 2.4 dBi at 2.4 GHz, ensuring improved signal reception and transmission via its omnidirectional radiation pattern. It is constructed for durability with IP65-rated protection, making it resistant to dust and water ingress, suitable for outdoor and harsh environmental applications. Operating across a temperature range from -30 to +60 degrees Celsius, it maintains performance under diverse conditions.
The TANGO25A antenna comes supplied with 100 mm of RG174 coaxial cable terminated with a reverse polarity SMA male connector, ensuring compatibility with a wide range of wireless devices. Its 50 ohm impedance and VSWR max of 2 provide excellent signal integrity and minimal reflection.
This antenna supports WiFi Dual Band, Bluetooth, and ZigBee wireless protocols, making it versatile for industrial, commercial, and smart home applications requiring robust connectivity.
The antenna supports WiFi (Dual Band) protocols for 2.4 GHz and 5 GHz bands. Designed in a compact stubby form factor measuring 22 mm diameter and height. Features a through hole/bolted external mounting with an 8 mm long screw thread.
Offers a gain of 2.4 dBi and omnidirectional radiation pattern. Constructed with IP65 protection for robust outdoor usage. Operates from -30 to +60 degrees Celsius. Includes 100 mm RG174 coaxial cable with reverse polarity SMA male connector.
50 ohm impedance and maximum VSWR of 2 for optimal performance. Supports WiFi, Bluetooth, and ZigBee protocols. Lightweight at approximately 13 g for easy device integration.
This antenna is ideal for industrial, telecommunications, smart home, laboratory, and commercial wireless systems requiring reliable dual band WiFi connectivity. It offers a compact and durable solution with easy mounting and broad protocol compatibility. Browse EnvMart’s extensive range of WiFi Antennas for more options.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports dual band WiFi protocols for 2.4 GHz and 5 GHz frequency bands.
This model operates efficiently within a temperature range of -30 to +60 degrees Celsius.
The antenna is designed in a compact stubby form factor, measuring 22 mm in diameter and height.
It utilizes a through hole/bolted mount with an 8 mm long screw thread for secure installation.
The impedance is rated at 50 ohms, ensuring effective signal matching.
It has an omnidirectional radiation pattern, allowing for reliable signal transmission in all directions.
The maximum VSWR for this antenna is 2, which helps maintain signal integrity.
The antenna weighs approximately 13 grams, making it lightweight for easy integration.
It is constructed with IP65 protection, making it resistant to dust and water for outdoor use.
