Siemens 5SV3 Series Residual Current Circuit Breaker, 16A, 2-Pole, 10mA Trip Sensitivity, Type A, 0.8 kA Breaking 5SV3111-6

Siemens 5SV3111-6 Residual Current Circuit Breaker is a high-quality protective device designed for residential and industrial electrical systems operating at 230V AC. It provides superior personnel and fire protection by rapidly interrupting fault currents at 16A current rating with 2 poles and 10mA trip sensitivity, suitable for sensitive residual current detection with Type A characteristics.

The device features a compact form factor with dimensions 72mm (W) x 90mm (H) x 70mm (D), optimized for DIN rail mounting assemblies. Its screw terminals ensure secure and reliable wiring connections. The electromagnetic tripping mechanism allows instantaneous break time to quickly isolate fault conditions.

Additional features include a toggle switch reset actuator for ease of operation and a breaking capacity of 0.8 kA to withstand surge currents above 1 kA. The enclosure is rated IP20, providing protection against solid objects larger than 12 mm, suitable for typical electrical panel environments. Operating ambient temperatures range between -25 and +45 degrees Celsius, making it adaptable across various climates.

This model complies with multiple international standards including EAC, VDE, UKCA, CE, and CCC, ensuring safety and quality assurance. Manufactured in Germany, these RCCBs possess an extended product life rated for over 10,000 switching cycles and exclude silicone for environmental safety.

Siemens 5SV3111-6 is ideal for installation in homes, commercial, and industrial facilities requiring dependable earth leakage protection. Its high trip sensitivity and robust build contribute to safeguarding human life and preventing electrical fires effectively.

Designed for personnel and fire protection with instantaneous break time. Type A tripping characteristics suitable for residual currents. DIN rail mountable with screw terminals. Breaking capacity rated at 0.8 kA ensuring high surge current withstand capability.

Operates reliably within ambient temperatures from -25 to +45 °C. IP20 enclosure for solid object protection. Toggle switch for reset actuation. Complies with EAC, VDE, UKCA, CE, and CCC standards. Manufactured in Germany with extended product life.

Equipment lifespan exceeds 10,000 switching cycles. Explore more high-quality circuit protection devices and electrical components in the Electronics & Electricals category at EnvMart.
